18
5. ELECTRICAL PARTS LIST
JACK MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
* 1-674-307-12 JACK BOARD
***********
< CAPACITOR >
C901 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C902 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C904 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN901 1-779-077-31 PLUG, CONNECTOR (CONTROL, AUDIO OUT)
CNJ901 1-778-775-21 CONNECTOR, FPC 13P
< FERRITE BEAD >
FB901 1-500-445-21 FERRITE 0uH
FB902 1-500-445-21 FERRITE 0uH
FB903 1-500-445-21 FERRITE 0uH
< IC LINK >
IC901 1-532-686-21 LINK, IC
**************************************************************
* A-3326-235-A MAIN BOARD, COMPLETE
*********************
1-676-339-11 MAIN FLEXIBLE BOARD
1-676-340-11 JACK FLEXIBLE BOARD
3-028-802-01 SPACER (MOUNT 30)
* 3-939-139-01 SPACER
< CAPACITOR >
C101 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C103 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C104 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C105 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C106 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C107 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C112 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C113 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C114 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C115 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C201 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C202 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C203 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C205 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C206 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C301 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C302 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C303 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C304 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C306 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C307 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C308 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C309 1-125-701-11 DOUBLE LAYER 0.047F 5.5V
C310 1-124-589-11 ELECT 47uF 20% 16V
C311 1-164-346-11 CERAMIC CHIP 1uF 16V
C314 1-124-589-11 ELECT 47uF 20% 16V
C315 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C316 1-115-466-00 ELECT 1000uF 20% 16V
C317 1-126-382-11 ELECT 100uF 20% 16V
C318 1-126-382-11 ELECT 100uF 20% 16V
C320 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C321 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C501 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C502 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C503 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C504 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C601 1-126-513-11 ELECT 47uF 20% 6.3V
C602 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C603 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C604 1-126-382-11 ELECT 100uF 20% 6.3V
C606 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C608 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C609 1-126-513-11 ELECT 47uF 20% 6.3V
C610 1-126-157-11 ELECT 10uF 20% 16V
C611 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C620 1-126-157-11 ELECT 10uF 20% 16V
C621 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C630 1-126-157-11 ELECT 10uF 20% 16V
C642 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
< DIODE >
D301 8-719-975-40 DIODE RB411D-T146
D302 8-719-017-94 DIODE MA8180-TX
D303 8-719-017-94 DIODE MA8180-TX
To Next Page
