Sony CDX-616 - Page 40

– 53 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< DIODE >
D301 8-719-975-40 DIODE RB411D-T146
D302 8-719-017-94 DIODE MA8180-TX
D303 8-719-017-94 DIODE MA8180-TX
D304 8-719-975-40 DIODE RB411D-T146
D305 8-719-975-40 DIODE RB411D-T146
D306 8-719-914-43 DIODE DAN202K-T-146
D307 8-719-069-56 DIODE UDZS-TE17-6.2B
D308 8-719-988-61 DIODE 1SS355TE-17
D309 8-719-053-18 DIODE 1SR154-400TE-25
D311 8-719-914-44 DIODE DAP202K-T-146
D312 8-719-069-57 DIODE UDZS-TE17-6.8B
D313 8-719-053-18 DIODE 1SR154-400TE-25
D314 8-719-975-40 DIODE RB411D-T146
D320 8-719-069-60 DIODE UDZS-TE17-9.1B
D501 8-719-988-61 DIODE 1SS355TE-17
D601 8-719-069-57 DIODE UDZS-TE17-6.8B
D602 8-719-069-57 DIODE UDZS-TE17-6.8B
< FERRITE BEAD >
FB601 1-500-445-21 FERRITE 0uH
< IC >
IC101 8-752-384-15 IC CXD2530Q
IC201 8-752-903-71 IC CXP84332-210Q
IC301 8-759-040-83 IC BA6287F-T1
IC302 8-759-444-86 IC BA8272F-E2
IC304 8-759-363-81 IC XC61AN4002PR
IC501 8-752-904-83 IC CXP83413-049Q
IC502 8-759-497-29 IC KM62256DLG-7LT
IC503 8-759-243-19 IC TC7SU04F-TE85L
IC601 8-759-494-78 IC TC9464FN-EL
< TRANSISTOR >
Q201 8-729-047-76 TRANSISTOR FMC2A-T148
Q301 8-729-028-62 TRANSISTOR DTA115EKA-T146
Q302 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q303 8-729-921-12 TRANSISTOR 2SD1834-T101
Q306 8-729-047-76 TRANSISTOR FMC2A-T148
Q307 8-729-019-00 TRANSISTOR 2SD2394-G
Q308 8-729-047-76 TRANSISTOR FMC2A-T148
Q309 8-729-019-00 TRANSISTOR 2SD2394-G
Q601 8-729-901-00 TRANSISTOR DTC124EKA-T146
Q602 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q610 8-729-015-39 TRANSISTOR DTC323TKT146
Q620 8-729-015-39 TRANSISTOR DTC323TKT146
< RESISTOR >
R101 1-216-105-00 RES, CHIP 220K 5% 1/10W
R102 1-216-121-00 RES, CHIP 1M 5% 1/10W
R103 1-216-113-00 METAL CHIP 470K 5% 1/10W
R104 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R105 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R106 1-216-073-00 METAL CHIP 10K 5% 1/10W
R107 1-216-121-00 RES, CHIP 1M 5% 1/10W
R108 1-216-097-00 RES, CHIP 100K 5% 1/10W
R109 1-216-073-00 METAL CHIP 10K 5% 1/10W
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-049-11 RES, CHIP 1K 5% 1/10W
R115 1-216-033-00 METAL CHIP 220 5% 1/10W
R116 1-216-033-00 METAL CHIP 220 5% 1/10W
R117 1-216-033-00 METAL CHIP 220 5% 1/10W
R202 1-216-097-00 RES, CHIP 100K 5% 1/10W
R203 1-216-097-00 RES, CHIP 100K 5% 1/10W
R204 1-216-097-00 RES, CHIP 100K 5% 1/10W
R205 1-216-097-00 RES, CHIP 100K 5% 1/10W
R206 1-216-097-00 RES, CHIP 100K 5% 1/10W
R207 1-216-049-11 RES, CHIP 1K 5% 1/10W
R211 1-216-097-00 RES, CHIP 100K 5% 1/10W
R212 1-216-097-00 RES, CHIP 100K 5% 1/10W
R213 1-216-097-00 RES, CHIP 100K 5% 1/10W
R219 1-216-049-11 RES, CHIP 1K 5% 1/10W
R220 1-216-097-00 RES, CHIP 100K 5% 1/10W
R301 1-216-089-00 RES, CHIP 47K 5% 1/10W
R302 1-216-097-00 RES, CHIP 100K 5% 1/10W
R303 1-216-099-00 METAL CHIP 120K 5% 1/10W
R304 1-216-089-00 RES, CHIP 47K 5% 1/10W
R306 1-216-101-00 METAL CHIP 150K 5% 1/10W
R309 1-216-089-00 RES, CHIP 47K 5% 1/10W
R311 1-216-101-00 METAL CHIP 150K 5% 1/10W
R312 1-216-073-00 METAL CHIP 10K 5% 1/10W
R314 1-216-295-00 SHORT 0
R316 1-216-073-00 METAL CHIP 10K 5% 1/10W
R318 1-216-033-00 METAL CHIP 220 5% 1/10W
R320 1-216-041-00 METAL CHIP 470 5% 1/10W
R321 1-216-041-00 METAL CHIP 470 5% 1/10W
R323 1-216-097-00 RES, CHIP 100K 5% 1/10W
R501 1-216-089-00 RES, CHIP 47K 5% 1/10W
R502 1-216-049-11 RES, CHIP 1K 5% 1/10W
R504 1-216-073-00 METAL CHIP 10K 5% 1/10W
R505 1-216-049-11 RES, CHIP 1K 5% 1/10W
R601 1-216-029-00 METAL CHIP 150 5% 1/10W
R602 1-216-033-00 METAL CHIP 220 5% 1/10W
R610 1-216-033-00 METAL CHIP 220 5% 1/10W
R611 1-216-097-00 RES, CHIP 100K 5% 1/10W
R612 1-216-295-00 SHORT 0
R620 1-216-033-00 METAL CHIP 220 5% 1/10W
R621 1-216-097-00 RES, CHIP 100K 5% 1/10W
R622 1-216-295-00 SHORT 0
R630 1-216-295-00 SHORT 0
< VARIABLE RESISTOR >
RV201 1-223-834-11 RES, ADJ, CARBON 47K
RV202 1-225-412-11 RES, VER, SLIDE 10K
(ELEVATOR HEIGHT SENSOR)
< SWITCH >
SW201 1-771-540-11 SWITCH, PUSH (1 KEY)
(MAGAZINE EJECT END DETECT)
SW202 1-771-540-11 SWITCH, PUSH (1 KEY)
(MAGAZINE IN/OUT DETECT)
SW301 1-571-532-21 SWITCH, TACTIL (6)
MAIN
