Sony CDX-616 - Page 75

21
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
RF SW
< SWITCH >
SW11 1-762-946-12 SWITCH, PUSH (1 KEY)
(CHUCKING END DETECT)
SW12 1-762-946-12 SWITCH, PUSH (1 KEY) (SAVE END DETECT)
**************************************************************
* 1-664-104-11 SW BOARD
*********
< SWITCH >
SW1 1-529-565-11 SWITCH, PUSH (1 KEY) (LIMIT)
**************************************************************
MISCELLANEOUS
**************
210 1-664-626-11 OP FLEXIBLE BOARD
0211 8-820-010-06 OPTICAL PICK-UP KSS-521A/K1RP
M101 A-3291-956-B MOTOR SUB ASSY, SPINDLE
M102 A-3291-955-A MOTOR SUB ASSY, SLED
M103 A-3301-123-A ELJ MOTOR ASSY (CHUCKING)
M104 A-3301-123-A ELJ MOTOR ASSY (ELEVATOR)
************************************************************
**************
HARDWARE LIST
**************
#3 7-685-781-09 SCREW +PTT 2X4 (S)
#4 7-624-104-04 STOPRING 2.0, TYPE -E
#5 7-627-554-07 SCREW, PRECISION +P 2X2.2
#6 7-628-253-00 SCREW +PS 2X4
#7 7-627-553-27 SCREW, PRECISION +P 2X2.5
#8 7-624-102-04 STOPRING 1.5, TYPE-E
#9 7-627-850-28 SCREW, PRECISION +P 1.4X3
#10 7-627-000-00 SCREW, PRECISION +P 1.7X2.2 TYPE 3
#12 7-685-780-09 SCREW +PTT 2X3 (S)
************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
