39
CDX-CA650/CA650V/CA650X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAINLIMIT LOADKEY
R946 1-216-031-00 METAL CHIP 180 5% 1/10W
(CA650V/CA650X)
R948 1-216-025-11 RES-CHIP 100 5% 1/10W
(CA650V)
R948 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650/CA650X)
R950 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650/CA650X)
R952 1-216-864-11 SHORT 0 (CA650/CA650X)
R953 1-216-037-00 RES-CHIP 330 5% 1/10W
(CA650V)
R954 1-216-809-11 METAL CHIP 100 5% 1/16W
R955 1-216-809-11 METAL CHIP 100 5% 1/16W
R956 1-216-809-11 METAL CHIP 100 5% 1/16W
R957 1-216-841-11 METAL CHIP 47K 5% 1/16W
R958 1-216-031-00 METAL CHIP 180 5% 1/10W
R959 1-216-031-00 METAL CHIP 180 5% 1/10W
R960 1-216-857-11 METAL CHIP 1M 5% 1/16W
R961 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R962 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R963 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R966 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650)
R967 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650)
R968 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650)
R969 1-216-023-00 METAL CHIP 82 5% 1/10W
(CA650V)
R969 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650/CA650X)
R971 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650/CA650X)
R972 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R978 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650)
R978 1-216-031-00 METAL CHIP 180 5% 1/10W
(CA650V/CA650X)
R979 1-216-029-00 METAL CHIP 150 5% 1/10W
(CA650)
R980 1-216-027-00 METAL CHIP 120 5% 1/10W
R981 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650)
R982 1-216-027-00 METAL CHIP 120 5% 1/10W
R983 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650)
R984 1-216-027-00 METAL CHIP 120 5% 1/10W
R985 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650)
R986 1-216-027-00 METAL CHIP 120 5% 1/10W
R987 1-216-027-00 METAL CHIP 120 5% 1/10W
(CA650)
< ROTARY ENCODER >
RE901 1-476-507-11 ENCODER, ROTARY
< SWITCH >
S902 1-771-884-11 SWITCH, TACTILE (WITH LED)
(M >/SEEK +)
S903 1-771-884-11 SWITCH, TACTILE (WITH LED)
(. m/SEEK –)
S904 1-771-884-11 SWITCH, TACTILE (WITH LED)
(DISC (PRST) +)
S905 1-771-884-11 SWITCH, TACTILE (WITH LED)
(DISC (PRST) –)
S906 1-771-884-11 SWITCH, TACTILE (WITH LED) (EQ7)
S907 1-771-884-11 SWITCH, TACTILE (WITH LED) (MBP)
*************************************************************
* 1-659-835-12 LIMIT BOARD
***********
< SWITCH >
SW3 1-572-688-11 SWITCH, PUSH (1 KEY) (LIMIT)
*************************************************************
* 1-659-837-11 LOAD BOARD
***********
< SWITCH >
SW4 1-572-288-21 SWITCH, PUSH (DOWN)
*************************************************************
* A-3326-846-A MAIN BOARD, COMPLETE (CA650)
* A-3326-849-A MAIN BOARD, COMPLETE (CA650X)
* A-3326-852-A MAIN BOARD, COMPLETE (CA650V)
*********************
* 3-040-998-01 BRACKET (IC)
* 3-041-011-01 HEAT SINK (REG)
* 3-223-780-11 HEAT SINK
* 3-223-783-01 CHASSIS (BACK)
7-685-647-79 SCREW +BVTP 3X10 TYPE 2 N-S
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
7-685-797-09 SCREW +PTT 2.6X16 (S)
< CAPACITOR >
C11 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C14 1-124-584-00 ELECT 100uF 20% 10V
C15 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C16 1-124-584-00 ELECT 100uF 20% 10V
C21 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C22 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C24 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C25 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C26 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C27 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C28 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C29 1-163-038-11 CERAMIC CHIP 0.1uF 25V
