41
CDX-CA650/CA650V/CA650X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
D473 8-719-081-83 DIODE CRG01(TE85L)
D474 8-719-081-83 DIODE CRG01(TE85L)
D475 8-719-081-83 DIODE CRG01(TE85L)
D476 8-719-081-83 DIODE CRG01(TE85L)
D477 8-719-081-83 DIODE CRG01(TE85L)
D478 8-719-081-83 DIODE CRG01(TE85L)
D479 8-719-073-01 DIODE MA111-(K8).S0
D551 8-719-056-82 DIODE UDZ-TE-17-6.2B
D553 8-719-056-93 DIODE UDZ-TE-17-18B
D554 8-719-056-93 DIODE UDZ-TE-17-18B
D555 8-719-420-51 DIODE MA729
D556 8-719-056-93 DIODE UDZ-TE-17-18B
D601 8-719-049-38 DIODE 1N5404TU
D609 8-719-056-83 DIODE UDZ-TE-17-6.8B
D610 8-719-056-65 DIODE 1SS372-TE85L
D611 8-719-053-18 DIODE 1SR154-400TE-25
D612 8-719-053-18 DIODE 1SR154-400TE-25
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-067-56 DIODE MA112-TX
D662 8-719-056-88 DIODE UDZ-TE-17-11B (CA650V)
D671 8-719-073-01 DIODE MA111-(K8).S0
D701 8-719-073-01 DIODE MA111-(K8).S0
D710 8-719-078-81 DIODE DF5A6.8FU(TE85R)
D711 8-719-078-81 DIODE DF5A6.8FU(TE85R)
D713 8-719-056-83 DIODE UDZ-TE-17-6.8B
D714 8-719-056-93 DIODE UDZ-TE-17-18B
D720 8-719-056-83 DIODE UDZ-TE-17-6.8B
< IC >
IC20 8-759-909-71 IC BA4558F-E2
IC51 8-759-492-59 IC SAA6588T/V2-118
IC401 8-759-827-13 IC TDA7406T
IC404 8-759-827-14 IC TA8268AH
IC501 6-800-078-01 IC MN101C49KTH1
IC505 8-759-449-89 IC BA8270F-E2
IC601 8-759-661-47 IC BA4908-V3
IC602 8-759-682-69 IC XC61CN4302MR
< JACK >
J10 1-815-185-11 JACK (ANTENNA)
J561 1-566-822-41 JACK (REMOTE IN)
< JUMPER RESISTOR >
JC1 1-216-295-11 SHORT 0
JC2 1-216-295-11 SHORT 0
JC3 1-216-295-11 SHORT 0
JC4 1-216-296-11 SHORT 0
JC5 1-216-296-11 SHORT 0
JC6 1-216-295-11 SHORT 0
JC7 1-216-296-11 SHORT 0
JC8 1-216-295-11 SHORT 0
JC9 1-216-296-11 SHORT 0
JC12 1-216-295-11 SHORT 0
< COIL >
L10 1-410-509-11 INDUCTOR 10uH
L50 1-410-509-11 INDUCTOR 10uH
L500 1-419-476-11 COIL, CHOKE 250uH
L501 1-410-509-11 INDUCTOR 10uH
< JACK >
PJ401 1-774-700-11 JACK, PIN 6P (BUS AUDIO IN,
AUDIO OUT FRONT/REAR)
< TRANSISTOR >
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q22 8-729-900-53 TRANSISTOR DTC114EK
Q331 8-729-021-82 TRANSISTOR 2SD2396K
Q332 8-729-047-76 TRANSISTOR FMC2A-T148
Q333 8-729-900-53 TRANSISTOR DTC114EK
Q341 8-729-920-85 TRANSISTOR 2SD1664-QR
Q431 8-729-920-21 TRANSISTOR DTC314TKH04
Q441 8-729-920-21 TRANSISTOR DTC314TKH04
Q451 8-729-920-21 TRANSISTOR DTC314TKH04
Q461 8-729-920-21 TRANSISTOR DTC314TKH04
Q478 8-729-900-53 TRANSISTOR DTC114EK
Q479 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q556 8-729-900-53 TRANSISTOR DTC114EK
Q631 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q660 8-729-903-46 TRANSISTOR 2SB1132-P (CA650/CA650X)
Q661 8-729-019-00 TRANSISTOR 2SD2394-G (CA650V)
Q662 8-729-047-76 TRANSISTOR FMC2A-T148
Q663 8-729-047-76 TRANSISTOR FMC2A-T148
Q664 8-729-027-23 TRANSISTOR DTA114EKA-T146
< RESISTOR >
R21 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R22 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R23 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R24 1-216-073-00 METAL CHIP 10K 5% 1/10W
R25 1-216-073-00 METAL CHIP 10K 5% 1/10W
R26 1-216-025-11 RES-CHIP 100 5% 1/10W
R27 1-216-097-11 RES-CHIP 100K 5% 1/10W
R28 1-216-121-11 RES-CHIP 1M 5% 1/10W
R29 1-216-025-11 RES-CHIP 100 5% 1/10W
R31 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R32 1-216-097-11 RES-CHIP 100K 5% 1/10W
R41 1-216-089-11 RES-CHIP 47K 5% 1/10W
R52 1-216-113-00 METAL CHIP 470K 5% 1/10W
R53 1-216-049-11 RES-CHIP 1K 5% 1/10W
R54 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R56 1-216-001-00 METAL CHIP 10 5% 1/10W
R57 1-216-041-00 METAL CHIP 470 5% 1/10W
R60 1-216-001-00 METAL CHIP 10 5% 1/10W
