16
CDX-GT30W/GT300/GT300EE/GT300S/GT350/GT350S
2-2. CD MECHANISM BLOCK
Note: Follow the disassembly procedure in the numerical order given.
2-1. SUB PANEL ASSY
2
two claw
s
3
two claws
5
sub panel assy
flexible flat cable (17 core)
(CN701)
4
1
two
screws
(+PTT 2.6
×
6)
6
bracket (CD)
7
CD mechanism block
4
CN350
3
1
screw
(+PTT 2.6
×
6
)
2
screw
(+PTT 2.6
×
6)
5
two
screws
(+PTT 2.6
×
4)
Ver. 1.2
