CDX-GT30W/GT300/GT300EE/GT300S/GT350/GT350S
2-10. SERVO BOARD
2-9. LE MOTOR ASSY (M903)
2 washer
4
qd
3 gear (LE1)
7 leaf spring (LE)
5
lever (D)
bracket (LEM-N)
slider (R)
6 screw
(+P 1.7
× 2.2)
8 screw
(+M 1.7
× 2.5)
qa screw
(+M 1.7
× 2.5)
qf two toothed lock screws
(+M 1.4
)
qs screw
(+M 1.7
× 2.5)
9 bearing (LEB-N)
0 gear (LE) assy
qg LE motor assy
(M903)
1 Remove the solders.
5 claw
6 SERVO board
4 screw
1 Remove the eight solders.
2 Remove the three solders.
3 optical pick-up (16 core)
(CN1)
