18
CDX-GT30W/GT300/GT300EE/GT300S/GT350/GT350S
2-6. CHASSIS (OP) ASSY
2-5. ROLLER ARM ASSY
3
washer
4
gear (RA1)
5
roller arm assy
1
spring (RAL-B)
2
spring (RAR-B)
4
washer
0
coil spring (damper)
9
two coil springs (damper)
qa
chassis (OP) assy
5
gear (LE1)
1
optical pick-up (16 core
)
(CN1)
lever (D)
slider (R)
6
7
8
2
Remove the six solders.
3
tension spring (KF60)
Ver. 1.2
