Sony CDX-GT35U Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CDX-GT35U/GT39U/GT39UE
3333
R990 1-216-809-11 METAL CHIP 100 5% 1/10W
R991 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R992 1-216-833-11 METAL CHIP 10K 5% 1/10W
R993 1-216-833-11 METAL CHIP 10K 5% 1/10W
R996 1-216-833-11 METAL CHIP 10K 5% 1/10W
R998 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB901 1-239-662-81 RESISTOR, NETWORK 10X2
< ROTARY ENCODER >
RE901 1-479-902-32 ENCODER, ROTARY
(PUSH ENTER/SELECT,VOLUME)
< SWITCH >
S902 1-786-653-21 SWITCH, TACTILE (m . SEEK–)
S903 1-786-653-21 SWITCH, TACTILE (
)
S904 1-786-653-21 SWITCH, TACTILE (MODE)
S905 1-786-653-21 SWITCH, TACTILE (SEEK+ > M)
S906 1-786-653-21 SWITCH, TACTILE (SOURCE)
S907 1-786-653-21 SWITCH, TACTILE (OFF)
S908 1-786-653-21 SWITCH, TACTILE ( )
< VARISTOR >
VDR900 1-804-988-21 VARISTOR, CHIP (1608)
VDR901 1-804-988-21 VARISTOR, CHIP (1608)
VDR903 1-804-988-21 VARISTOR, CHIP (1608)
VDR906 1-804-988-21 VARISTOR, CHIP (1608)
VDR908 1-804-988-21 VARISTOR, CHIP (1608)
*************************************************************
A-1738-025-A MAIN BOARD, COMPLETE (AEP,UK)
A-1738-283-A MAIN BOARD, COMPLETE (GT35U:RU)
A-1738-284-A MAIN BOARD, COMPLETE (GT39UE)
A-1738-285-A MAIN BOARD, COMPLETE (E,AR)
********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C6 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C8 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C9 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C12 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C13 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C16 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C18 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C19 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C20 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C21 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C25 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C28 1-126-947-11 ELECT 47uF 20% 35V
C101 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C103 1-126-961-11 ELECT 2.2uF 20% 50V
C104 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C108 1-126-964-11 ELECT 10uF 20% 50V
C109 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C110 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C114 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C115 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C116 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C201 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C203 1-126-961-11 ELECT 2.2uF 20% 50V
C204 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C210 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C211 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C212 1-126-964-11 ELECT 10uF 20% 50V
C213 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C214 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C215 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C217 1-126-964-11 ELECT 10uF 20% 50V
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C303 1-128-551-11 ELECT 22uF 20% 63V
C304 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C305 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C306 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C307 1-124-589-11 ELECT 47uF 20% 16V
C308 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-124-233-11 ELECT 10uF 20% 16V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-124-233-11 ELECT 10uF 20% 16V
C313 1-124-233-11 ELECT 10uF 20% 16V
C314 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C315 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-126-934-11 ELECT 220uF 20% 16V
C318 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C319 1-126-964-11 ELECT 10uF 20% 50V
C322 1-126-947-11 ELECT 47uF 20% 35V
C323 1-126-961-11 ELECT 2.2uF 20% 50V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C403 1-128-057-11 ELECT 330uF 20% 6.3V
C404 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C405 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C406 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C409 1-126-926-11 ELECT 1000uF 20% 10V
C411 1-126-924-11 ELECT 330uF 20% 10V
KEY MAIN
Ver. 1.1

Sony CDX-GT35U Specifications

General

MP3 playback	Yes
DVD Video playback	No
Preset stations quantity	30
Output power	180 W
Product color	Black
File type	MP3, WMA, AAC
I/O ports	1 x USB 1 x Aux in
Key illumination color	Red
Number of optical discs	1 discs
Illumination color	Blue
