Sony CDX-GT35U Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CDX-GT35U/GT39U/GT39UE
34
C413 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C420 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C421 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C422 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C425 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C427 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C429 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C433 1-124-589-11 ELECT 47uF 20% 16V
C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C435 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C436 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C502 1-165-727-31 ELECT 120uF 20% 16V
C503 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C506 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C507 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C508 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C509 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-126-924-11 ELECT 330uF 20% 10V
C516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C518 1-126-934-11 ELECT 220uF 20% 16V
C519 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C520 1-124-584-00 ELECT 100uF 20% 10V
C521 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C523 1-104-665-11 ELECT 100uF 20% 25V
C524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-124-584-00 ELECT 100uF 20% 10V
C702 1-124-234-00 ELECT 22uF 20% 16V
C703 1-124-233-11 ELECT 10uF 20% 16V
C704 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C707 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C804 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C805 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C806 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C807 1-112-302-11 ELECT 3300uF 20% 16V
C808 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C810 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C811 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C812 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C813 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN401 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
CN403 1-820-622-21 SOCKET, CONNECTOR 20P
CN501 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN701 1-820-611-11 CONNECTOR, BOARD TO BOARD 28P
CN802 1-774-701-21 PIN, CONNECTOR 16P
< DIODE >
D101 1-805-043-11 ABSORBER, CHIP SURGE
D104 6-502-643-01 DIODE 1A4-A2
D105 6-502-643-01 DIODE 1A4-A2
D201 1-805-043-11 ABSORBER, CHIP SURGE
D204 6-502-643-01 DIODE 1A4-A2
D205 6-502-643-01 DIODE 1A4-A2
D301 8-719-978-33 DIODE DTZ-TT11-6.8B
D302 6-502-643-01 DIODE 1A4-A2
D303 6-502-643-01 DIODE 1A4-A2
D304 6-502-643-01 DIODE 1A4-A2
D305 6-502-643-01 DIODE 1A4-A2
D306 6-501-817-01 DIODE MA2J1110GLS0
D308 6-501-817-01 DIODE MA2J1110GLS0
D309 6-501-817-01 DIODE MA2J1110GLS0
D401 6-502-131-01 DIODE LRB751V-40T1G
D403 6-501-743-01 DIODE MAZ8068GMLS0
D404 6-501-743-01 DIODE MAZ8068GMLS0
D410 6-501-743-01 DIODE MAZ8068GMLS0
D411 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
D502 6-501-817-01 DIODE MA2J1110GLS0
D503 6-501-768-01 DIODE MAZ8120GMLS0
D504 6-501-657-01 DIODE MA24D5000BS0
D505 6-501-734-01 DIODE MAZ8056GMLS0
D510 6-501-718-01 DIODE MAZ8039GLLS0
D511 6-501-817-01 DIODE MA2J1110GLS0
D512 6-501-817-01 DIODE MA2J1110GLS0
D701 6-501-656-01 DIODE LBAT54ALT1G
D806 6-501-747-01 DIODE MAZ8075GMLS0
D807 6-501-782-01 DIODE MAZ8180GMLS0
D808 6-501-782-01 DIODE MAZ8180GMLS0 (AEP,UK,RU)
D809 6-501-782-01 DIODE MAZ8180GMLS0
D810 6-501-782-01 DIODE MAZ8180GMLS0
D811 6-501-782-01 DIODE MAZ8180GMLS0
D812 6-501-571-01 DIODE 1N5404-C311-3
D813 6-502-643-01 DIODE 1A4-A2 (AEP,UK)
< FUSE >
F501 1-576-416-21 FUSE, MICRO (1608 TYPE) 2A
< FERRITE BEAD >
FB101 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB201 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB301 1-469-876-11 INDUCTOR, FERRITE BEAD
FB701 1-469-844-11 INDUCTOR 2.2uH
FB702 1-414-595-11 INDUCTOR, FERRITE BEAD
FB705 1-414-228-11 INDUCTOR, FERRITE BEAD
FB707 1-414-228-11 INDUCTOR, FERRITE BEAD
< IC >
IC001 6-714-162-01 IC TEF6617T/V1/S470,518 (E,RU,AR)
IC001 6-714-162-1
1 IC TEF6617T/V1/S470/M5,518 (AEP,UK)
IC301 6-705-359-02 IC TDA8588AJ/N2/R1 (E,AR)
IC301 6-705-362-02 IC TDA8589AJ/N2/R1 (RU)
IC301 6-705-362-11 IC TDA8589AJ/N2/R1/M5 (AEP,UK)
IC401 6-714-637-01 IC MB90F882PF-G-103E1
IC402 6-702-302-01 IC TK11133CSCL-G
IC403 6-712-776-01 IC PST8228UL
MAIN
Ver. 1.1

Sony CDX-GT35U Specifications

General

MP3 playback	Yes
DVD Video playback	No
Preset stations quantity	30
Output power	180 W
Product color	Black
File type	MP3, WMA, AAC
I/O ports	1 x USB 1 x Aux in
Key illumination color	Red
Number of optical discs	1 discs
Illumination color	Blue
