Sony CDX-GT35U Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CDX-GT35U/GT39U/GT39UE
3535
IC501 6-710-965-01 IC TPS40200DRG4
IC503 6-709-213-01 IC NJM2387ADL3(TE2)
IC804 6-714-420-01 IC BD3705FV-E2
< JACK >
J1 1-815-185-13 JACK (ANTENNA)
J303 1-774-698-41 JACK, PIN 2P (REAR/SUB AUDIO OUT)
J801 1-566-822-81 JACK (REMOTE IN) (AEP,UK,RU)
< JUMPER RESISTOR >
JC100 1-216-296-11 SHORT CHIP 0
JC101 1-216-295-91 SHORT CHIP 0
JC102 1-216-296-11 SHORT CHIP 0
JC103 1-216-296-11 SHORT CHIP 0
JC104 1-216-296-11 SHORT CHIP 0
JC105 1-216-295-91 SHORT CHIP 0
JC106 1-216-864-11 SHORT CHIP 0
JC107 1-216-295-91 SHORT CHIP 0
JC108 1-216-864-11 SHORT CHIP 0
JC109 1-216-864-11 SHORT CHIP 0
JC110 1-216-864-11 SHORT CHIP 0
JC111 1-216-296-11 SHORT CHIP 0
JC112 1-216-296-11 SHORT CHIP 0
JC113 1-216-296-11 SHORT CHIP 0
JC114 1-216-296-11 SHORT CHIP 0
JC115 1-216-864-11 SHORT CHIP 0
JC116 1-216-296-11 SHORT CHIP 0
JC117 1-216-295-91 SHORT CHIP 0
JC118 1-216-295-91 SHORT CHIP 0
JC119 1-216-296-11 SHORT CHIP 0
JC120 1-216-296-11 SHORT CHIP 0
JC121 1-216-295-91 SHORT CHIP 0
JC122 1-216-295-91 SHORT CHIP 0
JC123 1-216-296-11 SHORT CHIP 0
JC124 1-216-296-11 SHORT CHIP 0
JC125 1-216-864-11 SHORT CHIP 0
JC126 1-216-295-91 SHORT CHIP 0
JC127 1-216-295-91 SHORT CHIP 0
JC128 1-216-295-91 SHORT CHIP 0
JC129 1-216-295-91 SHORT CHIP 0
JC130 1-216-864-11 SHORT CHIP 0
JC131 1-216-296-11 SHORT CHIP 0
JC132 1-216-296-11 SHORT CHIP 0
JC133 1-216-296-11 SHORT CHIP 0
< COIL >
L1 1-414-180-51 INDUCTOR 3.3uH
L2 1-410-501-61 INDUCTOR 2.2uH
L6 1-457-817-11 COIL (FM MIX)
L7 1-481-285-51 INDUCTOR 560uH
L8 1-481-285-51 INDUCTOR 560uH
L301 1-469-844-11 INDUCTOR 2.2uH
L501 1-411-595-21 COIL, CHOKE 47uH
L502 1-406-718-21 COIL, CHOKE 68uH
L503 1-412-525-31 INDUCTOR 10uH
L801 1-456-617-11 COIL, CHOKE
< TRANSISTOR >
Q102 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q103 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q104 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q202 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q203 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q204 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q303 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q304 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q305 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q401 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q402 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q501 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q502 6-551-923-01 FET TPC6108(T5RSONYF,M
Q503 6-550-828-01 FET RSQ035P03TR
Q504 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q505 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q701 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q802 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q805 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q806 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF (AEP,UK,RU)
Q807 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q808 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1 1-216-853-11 METAL CHIP 470K 5% 1/10W
R2 1-216-853-11 METAL CHIP 470K 5% 1/10W
R3 1-216-864-11 SHORT CHIP 0
R4 1-216-864-11 SHORT CHIP 0
R5 1-216-864-11 SHORT CHIP 0
R6 1-216-843-11 METAL CHIP 68K 5% 1/10W
R10 1-216-839-11 METAL CHIP 33K 5% 1/10W
R11 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R12 1-216-009-91 METAL CHIP 22 5% 1/10W
R13 1-216-809-11 METAL CHIP 100 5% 1/10W
R14 1-216-809-11 METAL CHIP 100 5% 1/10W
R15 1-216-864-11 SHORT CHIP 0
R16 1-216-864-11 SHORT CHIP 0
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R103 1-216-817-11 METAL CHIP 470 5% 1/10W
R104 1-216-834-11 METAL CHIP 12K 5% 1/10W
R106 1-216-813-11 METAL CHIP 220 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R112 1-216-821-11 METAL CHIP 1K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-813-11 METAL CHIP 220 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R201 1-216-821-11 METAL CHIP 1K 5% 1/10W
R203 1-216-817-11 METAL CHIP 470 5% 1/10W
R204 1-216-834-11 METAL CHIP 12K 5% 1/10W
R206 1-216-813-11 METAL CHIP 220 5% 1/10W
R207 1-216-833-11 METAL CHIP 10K 5% 1/10W
R212 1-216-821-11 METAL CHIP 1K 5% 1/10W
R213 1-216-833-11 METAL CHIP 10K 5% 1/10W
R216 1-216-813-11 METAL CHIP 220 5% 1/10W
R217 1-216-833-11 METAL CHIP 10K 5% 1/10W
R222 1-216-864-11 SHORT CHIP 0
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R303 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R304 1-216-295-91 SHORT CHIP 0
R306 1-216-841-11 METAL CHIP 47K 5% 1/10W
R308 1-216-811-11 METAL CHIP 150 5% 1/10W
R309 1-216-797-11 METAL CHIP 10 5% 1/10W
MAIN

Sony CDX-GT35U Specifications

General

MP3 playback	Yes
DVD Video playback	No
Preset stations quantity	30
Output power	180 W
Product color	Black
File type	MP3, WMA, AAC
I/O ports	1 x USB 1 x Aux in
Key illumination color	Red
Number of optical discs	1 discs
Illumination color	Blue
