Sony CDX-GT71W Service Manual

55
CDX-GT71W/GT710/GT760
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R107 1-216-073-00 RES-CHIP 10K 5% 1/10W
R108 1-216-073-00 RES-CHIP 10K 5% 1/10W
R109 1-216-833-11 METAL CHIP 10K 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-841-11 METAL CHIP 47K 5% 1/10W
R112 1-216-821-11 METAL CHIP 1K 5% 1/10W
R114 1-216-809-11 METAL CHIP 100 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R118 1-216-821-11 METAL CHIP 1K 5% 1/10W
R119 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R120 1-216-073-00 RES-CHIP 10K 5% 1/10W
R121 1-216-073-00 RES-CHIP 10K 5% 1/10W
R122 1-216-845-11 METAL CHIP 100K 5% 1/10W
R123 1-216-837-11 METAL CHIP 22K 5% 1/10W
R126 1-216-851-11 METAL CHIP 330K 5% 1/10W
R127 1-216-851-11 METAL CHIP 330K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-833-11 METAL CHIP 10K 5% 1/10W
R172 1-216-864-11 SHORT CHIP 0
R174 1-216-813-11 METAL CHIP 220 5% 1/10W
R175 1-216-833-11 METAL CHIP 10K 5% 1/10W
R182 1-216-864-11 SHORT CHIP 0
R184 1-216-813-11 METAL CHIP 220 5% 1/10W
R185 1-216-833-11 METAL CHIP 10K 5% 1/10W
R201 1-216-841-11 METAL CHIP 47K 5% 1/10W
R202 1-216-811-11 METAL CHIP 150 5% 1/10W
R203 1-216-821-11 METAL CHIP 1K 5% 1/10W
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R206 1-216-821-11 METAL CHIP 1K 5% 1/10W
R207 1-216-864-11 SHORT CHIP 0
R242 1-216-821-11 METAL CHIP 1K 5% 1/10W
R243 1-216-833-11 METAL CHIP 10K 5% 1/10W
R264 1-216-864-11 SHORT CHIP 0
R272 1-216-864-11 SHORT CHIP 0
R274 1-216-813-11 METAL CHIP 220 5% 1/10W
R275 1-216-833-11 METAL CHIP 10K 5% 1/10W
R282 1-216-864-11 SHORT CHIP 0
R284 1-216-813-11 METAL CHIP 220 5% 1/10W
R285 1-216-833-11 METAL CHIP 10K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
(E,CH,MX,IND)
R303 1-216-845-11 METAL CHIP 100K 5% 1/10W
(E,CH,MX,IND)
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-216-833-11 METAL CHIP 10K 5% 1/10W
R306 1-216-845-11 METAL CHIP 100K 5% 1/10W
R307 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP,UK)
R309 1-216-845-11 METAL CHIP 100K 5% 1/10W
R310 1-216-839-11 METAL CHIP 33K 5% 1/10W
(AEP,UK)
R311 1-216-843-11 METAL CHIP 68K 5% 1/10W
(AEP,UK)
R312 1-216-843-11 METAL CHIP 68K 5% 1/10W
R313 1-216-839-11 METAL CHIP 33K 5% 1/10W
Ref. No. Part No. Description Remark
R314 1-216-843-11 METAL CHIP 68K 5% 1/10W
R315 1-216-842-11 METAL CHIP 56K 5% 1/10W
R318 1-216-833-11 METAL CHIP 10K 5% 1/10W
R319 1-216-821-11 METAL CHIP 1K 5% 1/10W
R321 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EXCEPT AEP,UK)
R322 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R323 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R327 1-216-849-11 METAL CHIP 220K 5% 1/10W
R328 1-216-849-11 METAL CHIP 220K 5% 1/10W
R332 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R333 1-216-809-11 METAL CHIP 100 5% 1/10W
R334 1-216-841-11 METAL CHIP 47K 5% 1/10W
R335 1-216-839-11 METAL CHIP 33K 5% 1/10W
R336 1-216-845-11 METAL CHIP 100K 5% 1/10W
R337 1-216-841-11 METAL CHIP 47K 5% 1/10W
R339 1-216-809-11 METAL CHIP 100 5% 1/10W
R340 1-216-821-11 METAL CHIP 1K 5% 1/10W
R341 1-216-821-11 METAL CHIP 1K 5% 1/10W
R342 1-216-845-11 METAL CHIP 100K 5% 1/10W
R343 1-216-809-11 METAL CHIP 100 5% 1/10W
R344 1-216-809-11 METAL CHIP 100 5% 1/10W
R345 1-216-809-11 METAL CHIP 100 5% 1/10W
R346 1-216-833-11 METAL CHIP 10K 5% 1/10W
R347 1-216-809-11 METAL CHIP 100 5% 1/10W
R348 1-216-833-11 METAL CHIP 10K 5% 1/10W
R350 1-216-809-11 METAL CHIP 100 5% 1/10W
R351 1-216-821-11 METAL CHIP 1K 5% 1/10W
R352 1-216-821-11 METAL CHIP 1K 5% 1/10W
R353 1-216-864-11 SHORT CHIP 0
R354 1-216-864-11 SHORT CHIP 0
R357 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R360 1-216-845-11 METAL CHIP 100K 5% 1/10W
(US,CND)
R361 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EXCEPT US,CND)
R362 1-216-845-11 METAL CHIP 100K 5% 1/10W
(EXCEPT AEP,UK)
R363 1-216-845-11 METAL CHIP 100K 5% 1/10W
(AEP,UK)
R364 1-216-845-11 METAL CHIP 100K 5% 1/10W
R365 1-216-845-11 METAL CHIP 100K 5% 1/10W
R366 1-216-845-11 METAL CHIP 100K 5% 1/10W
R368 1-216-864-11 SHORT CHIP 0
R369 1-216-864-11 SHORT CHIP 0
R370 1-216-864-11 SHORT CHIP 0
R372 1-216-864-11 SHORT CHIP 0
R373 1-216-845-11 METAL CHIP 100K 5% 1/10W
R375 1-216-845-11 METAL CHIP 100K 5% 1/10W
R377 1-216-845-11 METAL CHIP 100K 5% 1/10W
R380 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP,UK)
R381 1-216-864-11 SHORT CHIP 0
R382 1-216-864-11 SHORT CHIP 0
R383 1-216-864-11 SHORT CHIP 0
R384 1-216-864-11 SHORT CHIP 0
R391 1-216-845-11 METAL CHIP 100K 5% 1/10W
(US,CND,AEP,UK)
Ref. No. Part No. Description Remark
MAIN
Ver. 1.2
