Sony CDX-GT71W Service Manual

56
CDX-GT71W/GT710/GT760
R392 1-216-845-11 METAL CHIP 100K 5% 1/10W
R400 1-216-864-11 SHORT CHIP 0
R401 1-216-017-11 RES-CHIP 47 5% 1/10W
R402 1-216-813-11 METAL CHIP 220 5% 1/10W
R407 1-216-833-11 METAL CHIP 10K 5% 1/10W
R420 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R421 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R422 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R423 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R424 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R425 1-216-041-00 RES-CHIP 470 5% 1/10W
R426 1-216-041-00 RES-CHIP 470 5% 1/10W
R427 1-216-834-11 METAL CHIP 12K 5% 1/10W
R428 1-216-834-11 METAL CHIP 12K 5% 1/10W
R437 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R451 1-216-809-11 METAL CHIP 100 5% 1/10W
R452 1-216-864-11 SHORT CHIP 0
R453 1-216-864-11 SHORT CHIP 0
R454 1-216-864-11 SHORT CHIP 0
R455 1-216-864-11 SHORT CHIP 0
R486 1-216-864-11 SHORT CHIP 0
R501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R502 1-216-864-11 SHORT CHIP 0
R503 1-216-864-11 SHORT CHIP 0
R504 1-216-864-11 SHORT CHIP 0
R505 1-216-864-11 SHORT CHIP 0
R521 1-500-329-21 INDUCTOR, FERRITE BEAD
R522 1-500-329-21 INDUCTOR, FERRITE BEAD
R551 1-216-833-11 METAL CHIP 10K 5% 1/10W
(AEP,UK)
R552 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R553 1-216-801-11 METAL CHIP 22 5% 1/10W
(AEP,UK)
R554 1-216-845-11 METAL CHIP 100K 5% 1/10W
(AEP,UK)
R555 1-216-295-11 SHORT CHIP 0 (AEP,UK)
R556 1-216-295-11 SHORT CHIP 0 (AEP,UK)
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP,UK)
R620 1-216-230-00 RES-CHIP 22K 5% 1/8W
R621 1-216-230-00 RES-CHIP 22K 5% 1/8W
R622 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R623 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R624 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R625 1-216-025-11 RES-CHIP 100 5% 1/10W
R626 1-216-848-11 METAL CHIP 180K 5% 1/10W
R627 1-216-846-11 METAL CHIP 120K 5% 1/10W
R628 1-216-841-11 METAL CHIP 47K 5% 1/10W
R629 1-216-833-11 METAL CHIP 10K 5% 1/10W
R630 1-216-837-11 METAL CHIP 22K 5% 1/10W
R631 1-216-821-11 METAL CHIP 1K 5% 1/10W
R632 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R633 1-216-821-11 METAL CHIP 1K 5% 1/10W
R634 1-216-295-11 SHORT CHIP 0
R635 1-216-803-11 METAL CHIP 33 5% 1/10W
R636 1-211-985-11 METAL CHIP 47 0.5% 1/10W
R637 1-216-839-11 METAL CHIP 33K 5% 1/10W
R639 1-216-801-11 METAL CHIP 22 5% 1/10W
R640 1-216-845-11 METAL CHIP 100K 5% 1/10W
R644 1-216-134-00 RES-CHIP 2.2 5% 1/8W
R645 1-216-134-00 RES-CHIP 2.2 5% 1/8W
R647 1-216-134-00 RES-CHIP 2.2 5% 1/8W
R701 1-216-845-11 METAL CHIP 100K 5% 1/10W
R702 1-216-864-11 SHORT CHIP 0
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-864-11 SHORT CHIP 0
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R707 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R708 1-218-899-11 METAL CHIP 150K 0.5% 1/16W
R709 1-218-873-11 METAL CHIP 12K 0.5% 1/10W
R710 1-218-236-11 METAL CHIP 1 10% 1/4W
R711 1-218-236-11 METAL CHIP 1 10% 1/4W
< SWITCH >
S301 1-571-478-11 SWITCH, SLIDE (FREQUENCY SELECT)
(E,CH,MX,IND)
< TRANSFORMER >
T620 1-443-879-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
TH100 1-801-792-21 THERMISTOR, POSITIVE
TH301 1-804-045-11 THERMISTOR
< TUNER UNIT >
TUX501 A-3220-961-B TUNER UNIT (TUX-032)
< VIBRATOR >
X301 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
X302 1-781-679-11 VIBRATOR, CRYSTAL (6MHz)
X551 1-813-173-11 VIBRATOR, CRYSTAL (8.664MHz) (AEP,UK)
*************************************************************
A-1177-362-A SERVO BOARD, COMPLETE
**********************
*************************************************************
SUB PANEL BOARD
****************
< DIODE >
LED990 6-501-547-01 LED CL-197HB1E-D-T (DISC INDICATOR)
< RESISTOR >
R990 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R991 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN SERVO SUB PANEL
Ver. 1.2
