40
CDX-L250/L430X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C904 1-104-942-11 ELECT 1uF 20% 50V
C905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C907 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C910 1-124-259-11 ELECT 4.7uF 20% 16V
C913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C914 1-104-665-11 ELECT 100uF 20% 10V
C915 1-110-654-11 DOUBLE LAYERS 0.047F 5.5V
C916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C919 1-124-229-00 ELECT 33uF 20% 10V
C920 1-124-259-11 ELECT 4.7uF 20% 16V
C997 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< JACK >
CNJ601 1-793-598-11 JACK (ANT)
< CONNECTOR >
CNP501 1-774-701-11 PIN, CONNECTOR 16P
CNP701 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P
CNP802 1-569-853-11 SOCKET, CONNECTOR 10P
< SURGE ABSORBER >
CP601 1-803-335-21 ABSORBER, CHIP SURGE
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D444 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D604 8-719-109-89 DIODE RD5.6ESB2
D901 8-719-049-38 DIODE 1N5404TU
D903 8-719-109-97 DIODE RD6.8ESB2
D904 8-719-200-82 DIODE 11ES2
D906 8-719-921-63 DIODE MTZJ-7.5B
D907 8-719-110-49 DIODE RD18ESB2
D908 8-719-921-63 DIODE MTZJ-7.5B
D909 8-719-109-97 DIODE RD6.8ESB2
D910 8-719-109-89 DIODE RD5.6ESB2
D913 8-719-110-14 DIODE RD9.1ESB3
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-079-42 DIODE 1ZB22(TPA3)
D916 8-719-079-42 DIODE 1ZB22(TPA3)
D917 8-719-079-42 DIODE 1ZB22(TPA3)
D918 8-719-079-42 DIODE 1ZB22(TPA3)
D919 8-719-079-42 DIODE 1ZB22(TPA3)
D920 8-719-079-97 DIODE CRZ22(TE85L.SONY)
D921 8-719-079-97 DIODE CRZ22(TE85L.SONY)
D922 8-719-079-42 DIODE 1ZB22(TPA3)
D923 8-719-110-14 DIODE RD9.1ESB3
D930 8-719-109-89 DIODE RD5.6ESB2
D999 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-759-699-07 IC TA8263AH
IC401 8-759-827-11 IC LC75421M-TLM
IC601 8-759-586-59 IC TB2118F(EL)
IC801 8-759-837-06 IC uPD780024AGK-B26-9ET
IC902 8-759-837-07 IC S7139SF
< JUMPER RESISTOR >
JR1 1-216-864-11 SHORT 0
JR101 1-216-864-11 SHORT 0
JR601 1-216-864-11 SHORT 0
JR602 1-216-864-11 SHORT 0
JR901 1-216-864-11 SHORT 0
JR902 1-216-864-11 SHORT 0
JR929 1-216-864-11 SHORT 0
< COIL >
L601 1-410-515-11 INDUCTOR 33uH
L603 1-412-006-31 INDUCTOR 10uH
L604 1-410-750-41 INDUCTOR 0.47uH
L666 1-410-502-11 INDUCTOR 2.7uH
L667 1-424-759-21 COIL (AM ANT)
L702 1-410-513-11 INDUCTOR 22uH
L703 1-410-513-11 INDUCTOR 22uH
L901 1-419-476-31 COIL, CHOKE 250uH
< JACK >
PJ401 1-774-698-11 JACK, PIN 2P (AUDIO OUT)
< TRANSISTOR >
Q101 8-729-920-21 TRANSISTOR DTC314TKH04
Q102 8-729-920-21 TRANSISTOR DTC314TKH04
Q201 8-729-920-21 TRANSISTOR DTC314TKH04
Q202 8-729-920-21 TRANSISTOR DTC314TKH04
Q401 8-729-055-92 TRANSISTOR SRA2203S
Q402 8-729-055-96 TRANSISTOR SRC1203S
Q601 8-729-055-96 TRANSISTOR SRC1203S
Q602 8-729-049-40 TRANSISTOR STC2412G
Q603 8-729-030-51 TRANSISTOR 2SA1515S-R-TP
Q604 8-729-055-96 TRANSISTOR SRC1203S
Q605 8-729-030-51 TRANSISTOR 2SA1515S-R-TP
Q606 8-729-055-96 TRANSISTOR SRC1203S
Q901 8-729-049-40 TRANSISTOR STC2412G
Q902 8-729-049-40 TRANSISTOR STC2412G
Q903 8-729-055-96 TRANSISTOR SRC1203S
Q904 8-729-055-96 TRANSISTOR SRC1203S
Q905 8-729-055-96 TRANSISTOR SRC1203S
Q906 8-729-055-92 TRANSISTOR SRA2203S
Q907 8-729-021-82 TRANSISTOR 2SD2396K
Q909 8-729-055-96 TRANSISTOR SRC1203S
Q910 8-729-052-35 TRANSISTOR STD1664
Q911 8-729-055-96 TRANSISTOR SRC1203S
