9
CDX-L250/L430X
SECTION 2
DISASSEMBLY
Note : This set can be disassemble according to the following sequence.
Note : Follow the disassembly procedure in the numerical order given.
2-1. FRONT PANEL ASSY
claws
1 claws
3 CNP802
4 front panel assy
2 claws
Set Front Panel Assy CD Mechanism Block
Chassis (T) Sub Assy Lever Section
Servo Board
Shaft Roller Assy
Floating Block Assy Optical Pick-up Block
Main Board Heat Sink
