Sony CDX-M600R - Specifications

40
Specifications
MD player section
Signal-to-noise ratio 90 dB
Frequency response 10 – 20,000 Hz
Wow and flutter Below measurable limit
Tuner section
FM
Tuning range 87.5 – 108.0 MHz
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 8 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 66 dB (stereo),
72 dB (mono)
Harmonic distortion at 1 kHz
0.6 % (stereo),
0.3 % (mono)
Separation 35 dB at 1 kHz
Frequency response 30 – 15,000 Hz
MW/LW
Tuning range MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity MW: 30 µV
LW: 40 µV
Power amplifier section
Outputs Speaker outputs
Speaker impedance 4 – 8 ohms
Maximum power output 50 W × 4 (at 4 ohms)
General
Outputs Audio outputs*
1
Power aerial relay control
lead
Power amplifier control
lead
Inputs Telephone ATT control lead
Illumination control lead
Tone controls (CDX-M600R only)
Bass ±9 dB at 100 Hz
Treble ±9 dB at 10 kHz
Power requirements 12 V DC car battery
(negative ground)
Dimensions Approx. 178 × 50 × 182 mm
(w/h/d)
Mounting dimensions Approx. 182 × 53 × 163 mm
(w/h/d)
Mass Approx. 1.5 kg
Supplied accessories Card remote commander
RM-X95 (CDX-M700R only)
RM-X96 (CDX-M600R only)
Parts for installation and
connections (1 set)
Optional accessories Rotary commander
RM-X4S
BUS cable (supplied with an
RCA pin cord)
RC-61 (1 m), RC-62 (2 m)
Compact disc single
adaptor CSA-8
Optional equipment CD changer (10 discs)
CDX-828, CDX-737
MD changer (6 discs)
MDX-65
Other CD/MD units with
the Sony-BUS system
Source selector
XA-C30
DAB tuner unit
XT-100DAB
Digital equalizer
preamplifier*
2
XDP-210EQ, XDP-4000X
*
1
Equipped with front, rear and sub outputs:
CDX-M700R only
Equipped with front and rear outputs:
CDX-M600R only
*
2
CDX-M600R only
Design and specifications are subject to change
without notice.
