33
CDX-R3350/R3350C
SECTION 4
EXPLODED VIEWS
Ref. No. Part No. Description Remark
4-1. MAIN SECTION
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
NOTE:
• The mechanical parts with no reference
number in the exploded views are not supplied.
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Color Indication of Appearance Parts
Example :
KNOB, BALANCE (WHITE) ... (RED)
Parts Color Cabinet’s Color
• Accessories are given in the last of this
parts list.
RR
1 X-2024-491-1 PANEL ASSY, SUB
23-042-244-11 SCREW (T)
3 X-3383-739-1 LOCK ASSY (S)
42-050-124-01 SCREW +BTT 2.6X5 (R3350C)
43-376-464-11 SCREW (+PTT 2.6X6), GROUND POINT (R3350)
5 A-1086-104-A MAIN BOARD, COMPLETE (R3350)
5 A-1086-106-A MAIN BOARD, COMPLETE (R3350C)
6 2-021-848-01 SHEET (TU), GROUND
7 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)
FU601 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
TU1 A-3220-961-A TUNER UNIT (TUX-032)
#1 7-685-792-09 SCREW +PTT 2.6X6 (S)
#2 7-685-790-01 SCREW +PTT 2.6X4 (S)
#3 7-685-793-09 SCREW +PTT 2.6X8 (S)
FU601
not supplied
not supplied
not supplied
TU1
not supplied
#1
#1
#1
#2
#3
#1
MG-611TA-186//Q
A
A
B
B
1
2
3
4
7
5
6
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
