39
CDX-R3350/R3350C
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA..: µPA..
uPB.. : µPB.. uPC..: µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
KEY BOARD
**********
1-780-096-11 CONDUCTIVE BOARD, CONNECTION
2-515-402-11 SHEET (ILLUMINATOR)
< CAPACITOR >
C903 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C904 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(R3350C)
C905 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C906 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(R3350C)
C971 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C991 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C995 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CN901 1-794-312-11 PIN, CONNECTOR 12P
< DIODE >
D901 6-500-886-01 DIODE RSA6.1ENTR
D902 8-719-056-93 DIODE UDZ-TE-17-18B
D991 8-719-976-99 DIODE DTZ5.1B
D992 8-719-081-97 DIODE MMDL914T1
< IC >
IC901 6-707-063-01 IC LC75826WH-US-E
IC971 6-600-163-01 IC RS-770 (IR)
< LIQUID CRYSTAL DISPLAY >
LCD901 1-805-733-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED902 6-500-450-01 LED CL-195SR-CD-T (OFF) (R3350)
LED902 6-500-509-01 LED CL-165D/PG-D-T (OFF) (R3350C)
LED903 6-500-450-01 LED CL-195SR-CD-T (SOURCE) (R3350)
LED903 6-500-509-01 LED CL-165D/PG-D-T (SOURCE) (R3350C)
LED904 6-500-450-01 LED CL-195SR-CD-T (VOLUME –) (R3350)
LED904 6-500-509-01 LED CL-165D/PG-D-T (VOLUME –) (R3350C)
LED905 6-500-450-01 LED CL-195SR-CD-T (ATT) (R3350)
LED905 6-500-509-01 LED CL-165D/PG-D-T (ATT) (R3350C)
LED906 6-500-450-01 LED CL-195SR-CD-T (VOLUME +) (R3350)
LED906 6-500-509-01 LED CL-165D/PG-D-T (VOLUME +) (R3350C)
LED907 6-500-450-01 LED CL-195SR-CD-T (MODE) (R3350)
LED907 6-500-509-01 LED CL-165D/PG-D-T (MODE) (R3350C)
LED908 6-500-450-01 LED CL-195SR-CD-T (SEL) (R3350)
LED908 6-500-509-01 LED CL-165D/PG-D-T (SEL) (R3350C)
LED910 6-500-450-01 LED CL-195SR-CD-T (EQ3) (R3350)
LED910 6-500-509-01 LED CL-165D/PG-D-T (EQ3) (R3350C)
LED911 6-500-450-01 LED CL-195SR-CD-T (SEEK > M +)
(R3350)
LED911 6-500-509-01 LED CL-165D/PG-D-T (SEEK > M +)
(R3350C)
LED912 6-500-450-01 LED CL-195SR-CD-T (SEEK – m .)
(R3350)
LED912 6-500-509-01 LED CL-165D/PG-D-T (SEEK – m .)
(R3350C)
LED913 6-500-450-01 LED CL-195SR-CD-T (PTY) (R3350)
LED913 6-500-509-01 LED CL-165D/PG-D-T (PTY/LIST) (R3350C)
LED914 6-500-450-01 LED CL-195SR-CD-T (AF/TA) (R3350)
LED914 6-500-509-01 LED CL-165D/PG-D-T (AF/TA) (R3350C)
LED915 6-500-450-01 LED CL-195SR-CD-T (SENS) (R3350)
LED915 6-500-509-01 LED CL-165D/PG-D-T (SENS) (R3350C)
LED916 6-500-450-01 LED CL-195SR-CD-T (6) (R3350)
LED916 6-500-509-01 LED CL-165D/PG-D-T (6) (R3350C)
LED917 6-500-450-01 LED CL-195SR-CD-T (5) (R3350)
LED917 6-500-509-01 LED CL-165D/PG-D-T (5) (R3350C)
LED918 6-500-450-01 LED CL-195SR-CD-T (4) (R3350)
LED918 6-500-509-01 LED CL-165D/PG-D-T (4) (R3350C)
LED919 6-500-450-01 LED CL-195SR-CD-T (3) (R3350)
LED919 6-500-509-01 LED CL-165D/PG-D-T (3) (R3350C)
LED920 6-500-450-01 LED CL-195SR-CD-T (2) (R3350)
LED920 6-500-509-01 LED CL-165D/PG-D-T (2) (R3350C)
LED921 6-500-450-01 LED CL-195SR-CD-T (1) (R3350)
LED921 6-500-509-01 LED CL-165D/PG-D-T (1) (R3350C)
LED922 6-500-450-01 LED CL-195SR-CD-T (DSPL) (R3350)
LED922 6-500-509-01 LED CL-165D/PG-D-T (DSPL) (R3350C)
LED932 6-501-062-01 LED NSCW505CT-AST (LCD BACK LIGHT)
LED961 6-500-450-01 LED CL-195SR-CD-T (DISC IN) (R3350)
LED961 6-500-509-01 LED CL-165D/PG-D-T (DISC IN) (R3350C)
< RESISTOR >
LED931 1-216-174-00 RES-CHIP 100 5% 1/8W
< TRANSISTOR >
Q901 6-551-244-01 TRANSISTOR MUN2233T1G
Q902 6-551-244-01 TRANSISTOR MUN2233T1G (R3350C)
