Sony CDX-R3350 - Main Board and Chassis Assembly

9
CDX-R3350/R3350C
2-4. CHASSIS (T) SUB ASSY
2-3. MAIN BOARD
1 three screws
(+BTT 2.6 x 5)
3 MAIN board
4 insulating sheet
2 two screws
(+PTT 2.6
x 8
)
5 SENSOR board
6 chassis (T) sub assy
4 claw
3 claw
1 two screws
(+P 1.7
x 2.2)
2 two screws
(+P 1.7
x 2.2)
