44
CDX-R3350/R3350C
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R548 1-216-845-11 METAL CHIP 100K 5% 1/10W
(R3350C)
R550 1-216-845-11 METAL CHIP 100K 5% 1/10W
(R3350)
R551 1-216-845-11 METAL CHIP 100K 5% 1/10W
R552 1-216-845-11 METAL CHIP 100K 5% 1/10W
R553 1-216-839-11 METAL CHIP 33K 5% 1/10W
(R3350C)
R554 1-216-849-11 METAL CHIP 220K 5% 1/10W
(R3350C)
R555 1-216-849-11 METAL CHIP 220K 5% 1/10W
(R3350C)
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
R561 1-216-845-11 METAL CHIP 100K 5% 1/10W
R563 1-216-845-11 METAL CHIP 100K 5% 1/10W
R564 1-216-845-11 METAL CHIP 100K 5% 1/10W
R565 1-216-845-11 METAL CHIP 100K 5% 1/10W
R566 1-216-845-11 METAL CHIP 100K 5% 1/10W
R567 1-216-845-11 METAL CHIP 100K 5% 1/10W
R569 1-216-809-11 METAL CHIP 100 5% 1/10W
R570 1-216-817-11 METAL CHIP 470 5% 1/10W
R573 1-216-845-11 METAL CHIP 100K 5% 1/10W
R574 1-216-845-11 METAL CHIP 100K 5% 1/10W
R576 1-216-845-11 METAL CHIP 100K 5% 1/10W
R578 1-216-821-11 METAL CHIP 1K 5% 1/10W
R580 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3350C)
R581 1-216-809-11 METAL CHIP 100 5% 1/10W
(R3350C)
R582 1-216-821-11 METAL CHIP 1K 5% 1/10W
(R3350)
R582 1-216-835-11 METAL CHIP 15K 5% 1/10W
(R3350C)
R583 1-216-821-11 METAL CHIP 1K 5% 1/10W
R584 1-216-841-11 METAL CHIP 47K 5% 1/10W
R585 1-216-849-11 METAL CHIP 220K 5% 1/10W
(R3350)
R587 1-216-821-11 METAL CHIP 1K 5% 1/10W
(R3350C)
R588 1-216-821-11 METAL CHIP 1K 5% 1/10W
(R3350C)
R590 1-216-864-11 SHORT CHIP 0
R591 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(R3350C)
R601 1-216-845-11 METAL CHIP 100K 5% 1/10W
R609 1-216-821-11 METAL CHIP 1K 5% 1/10W
R631 1-249-425-11 CARBON 4.7K 5% 1/4W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R633 1-216-841-11 METAL CHIP 47K 5% 1/10W
R634 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R636 1-216-845-11 METAL CHIP 100K 5% 1/10W
R651 1-216-821-11 METAL CHIP 1K 5% 1/10W
R652 1-216-841-11 METAL CHIP 47K 5% 1/10W
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R671 1-216-809-11 METAL CHIP 100 5% 1/10W
R672 1-216-833-11 METAL CHIP 10K 5% 1/10W
R673 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R674 1-216-845-11 METAL CHIP 100K 5% 1/10W
R675 1-216-821-11 METAL CHIP 1K 5% 1/10W
R676 1-216-821-11 METAL CHIP 1K 5% 1/10W
R677 1-216-821-11 METAL CHIP 1K 5% 1/10W
R678 1-216-821-11 METAL CHIP 1K 5% 1/10W
(R3350C)
R679 1-216-821-11 METAL CHIP 1K 5% 1/10W
R681 1-216-864-11 SHORT CHIP 0
R704 1-216-864-11 SHORT CHIP 0
R705 1-216-809-11 METAL CHIP 100 5% 1/10W
R752 1-216-811-11 METAL CHIP 150 5% 1/10W
R756 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
S702 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR (POSITIVE) >
TH580 1-803-350-21 THERMISTOR, POSITIVE (R3350C)
< TUNER >
TU1 A-3220-961-A TUNER UNIT (TUX-032)
< VIBRATOR >
X51 1-813-532-11 VIBRATOR, CRYSTAL (8.664MHz)
X501 1-813-524-21 VIBRATOR, CERAMIC (18.432MHz)
X502 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
SENSOR BOARD
**************
< SWITCH >
SW2 1-529-566-61 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-61 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
A-1082-772-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C4 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C9 1-104-609-11 ELECT CHIP 100uF 20% 4V
C10 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C13 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C16 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C17 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C18 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C19 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C21 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C22 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C23 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C24 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C27 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C28 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C29 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C31 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
MAIN SERVOSENSOR
