Sony CFD-E75 - ICs, RESISTORS, AND TRANSISTORS

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
48
CFD-E75
< RESISTOR >
JC701 1-216-864-11 METAL CHIP 0 5% 1/16W
JC702 1-216-864-11 METAL CHIP 0 5% 1/16W
JC703 1-216-864-11 METAL CHIP 0 5% 1/16W
JC704 1-216-813-11 METAL CHIP 220 5% 1/16W
< FERRITE BEAD >
L706 1-414-445-11 FERRITE 0uH
< TRANSISTOR >
Q701 8-729-054-57 TRANSISTOR KTN2907AS-RTK
< RESISTOR >
R701 1-216-841-11 METAL CHIP 47K 5% 1/16W
R702 1-216-835-11 METAL CHIP 15K 5% 1/16W
R703 1-216-835-11 METAL CHIP 15K 5% 1/16W
R704 1-216-835-11 METAL CHIP 15K 5% 1/16W
R705 1-216-835-11 METAL CHIP 15K 5% 1/16W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R707 1-216-797-11 METAL CHIP 10 5% 1/16W
R708 1-216-833-11 METAL CHIP 10K 5% 1/16W
R709 1-216-837-11 METAL CHIP 22K 5% 1/16W
R710 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R711 1-216-815-11 METAL CHIP 330 5% 1/16W
R712 1-216-809-11 METAL CHIP 100 5% 1/16W
R714 1-216-811-11 METAL CHIP 150 5% 1/16W
R715 1-216-811-11 METAL CHIP 150 5% 1/16W
R716 1-216-821-11 METAL CHIP 1K 5% 1/16W
R717 1-216-821-11 METAL CHIP 1K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-809-11 METAL CHIP 100 5% 1/16W
R720 1-216-809-11 METAL CHIP 100 5% 1/16W
R721 1-216-821-11 METAL CHIP 1K 5% 1/16W
R722 1-216-809-11 METAL CHIP 100 5% 1/16W
R723 1-216-809-11 METAL CHIP 100 5% 1/16W
R724 1-216-841-11 METAL CHIP 47K 5% 1/16W
R725 1-216-819-11 METAL CHIP 680 5% 1/16W
R726 1-216-819-11 METAL CHIP 680 5% 1/16W
R727 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R728 1-216-833-11 METAL CHIP 10K 5% 1/16W
R729 1-216-813-11 METAL CHIP 220 5% 1/16W
R730 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R741 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R743 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R744 1-216-845-11 METAL CHIP 100K 5% 1/16W
< SWITCH >
S701 1-762-812-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-795-173-21 VIBRATOR, CERAMIC (33.8688MHz)
**************************************************************
* 1-681-672-13 JOG BOARD
**********
< ROTARY ENCODER >
RE401 1-476-747-11 ENCODER (JOG DIAL)
< SWITCH >
S406 1-554-937-11 SWITCH, KEYBOARD (DSPL ENT MEM)
S407 1-554-937-11 SWITCH, KEYBOARD (MENU ALARM)
**************************************************************
* 1-681-673-13 KEY POWER BOARD
****************
< CONNECTOR >
* CNP401 1-785-657-11 PIN, CONNECTOR (PC BOARD) 5P
* CNP402 1-785-654-11 PIN, CONNECTOR (PC BOARD) 2P
< RESISTOR >
R402 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R403 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R404 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R405 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R406 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R408 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R422 1-216-811-11 METAL CHIP 150 5% 1/16W
< SWITCH >
S401 1-554-937-11 SWITCH, KEYBOARD (POWER)
S402 1-554-937-11 SWITCH, KEYBOARD (STANDBY)
S403 1-554-937-11 SWITCH, KEYBOARD
(RADIO BAND AUTO PRESET)
S404 1-554-937-11 SWITCH, KEYBOARD (TUNE m –)
S405 1-554-937-11 SWITCH, KEYBOARD (TUNE M +)
**************************************************************
* 1-681-674-13 KEY VOLUME BOARD
****************
< RESISTOR >
R409 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R410 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R411 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R412 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R413 1-216-835-11 METAL CHIP 15K 5% 1/16W
< SWITCH >
S408 1-554-937-11 SWITCH, KEYBOARD (x)
S409 1-554-937-11 SWITCH, KEYBOARD (u)
S410 1-554-937-11 SWITCH, KEYBOARD (VOLUME –)
S411 1-554-937-11 SWITCH, KEYBOARD (VOLUME +)
S412 1-554-937-11 SWITCH, KEYBOARD (MEGA BASS)
S413 1-554-937-11 SWITCH, KEYBOARD (MODE)
**************************************************************
CD JOG KEY POWER KEY VOLUME
