Sony CFD-S26 - Printed Wiring Boards - Main Section (Former Type)

CFD-S26
2424
6-7. PRINTED WIRING BOARDS — MAIN SECTION (FORMER TYPE) — • Refer to page 19 for Circuit Boards Location and page 22 for Common Note on Printed Wiring Boards.
(Page 22)
(Page 29)
(Page 31)
1
A
B
C
D
E
F
G
H
I
J
234567891011
13 14
L-CH
R-CH
1
CD BOARD
CNP702
2
CONTROL (1) BOARD
CNP401
S801
Z PUSH OPEN/CLOSE
L3
AM
FERRITE-ROD
ANTENNA
3
POWER (1) BOARD
CNP902
ANT1
FM
TELESCOPIC
ANTENNA
MAIN BOARD
LCD801
LIQUID CRYSTAL DISPLAY PANEL
1-679-963-
1-679-592-
TP
(VT)
AUS,SP MODEL
SP MODEL
US,E,AUS MODEL
SP MODEL
SP MODEL
SP MODEL
D1 D-3
D2 D-4
D3 D-4
D10 B-2
D11 B-2
D322 H-9
D323 G-10
D324 C-9
D802 H-9
D803 C-9
D806 G-8
D807 G-9
<D951> D-10
<D952> E-9
D953 E-10
D957 E-9
IC1 C-3
IC2 C-5
(IC301) H-3
IC302 F-9
IC304 F-11
IC801 F-6
IC802 H-7
IC803 F-5
IC804 G-5
Q122 G-9
Q124 F-10
Q125 F-8
Q222 F-9
Q224 F-10
Q225 E-8
(Q301) G-2
Q801 H-9
Q804 G-9
Q806 H-9
Q807 C-11
Q808 C-9
Q812 G-8
Q813 G-8
Q814 C-6
Q817 E-9
Q818 E-8
Q819 H-9
Q820 E-5
<Q951> D-11
Q952 D-10
Q953 D-10
Q955 E-9
Q957 E-8
• Semiconductor
Location
Ref. No. Location
< > : SP MODEL ONLY
( ) : PRE BOARD
