57
CFD-S26
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< FERRITE BEAD >
FB701 1-469-701-21 INDUCTOR, FERRITE BEAD
< IC >
IC701 8-759-830-25 IC LC78645E
IC702 8-759-591-62 IC BA6998FP
< JUMPER RESISTOR >
JC701 1-216-864-11 METAL CHIP 0 5% 1/16W
JC702 1-216-864-11 METAL CHIP 0 5% 1/16W
JC703 1-216-864-11 METAL CHIP 0 5% 1/16W
JC704 1-216-813-11 METAL CHIP 220 5% 1/16W
< FERRITE BEAD >
L706 1-414-445-11 FERRITE, EMI (SMD)
< TRANSISTOR >
Q701 8-729-054-57 TRANSISTOR KTN2907AS-RTK
< RESISTOR >
R701 1-216-841-11 METAL CHIP 47K 5% 1/16W
R702 1-216-835-11 METAL CHIP 15K 5% 1/16W
R703 1-216-835-11 METAL CHIP 15K 5% 1/16W
R704 1-216-835-11 METAL CHIP 15K 5% 1/16W
R705 1-216-835-11 METAL CHIP 15K 5% 1/16W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R707 1-216-797-11 METAL CHIP 10 5% 1/16W
R708 1-216-833-11 METAL CHIP 10K 5% 1/16W
R709 1-216-837-11 METAL CHIP 22K 5% 1/16W
R710 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R711 1-216-815-11 METAL CHIP 330 5% 1/16W
R712 1-216-809-11 METAL CHIP 100 5% 1/16W
R714 1-216-811-11 METAL CHIP 150 5% 1/16W
R715 1-216-811-11 METAL CHIP 150 5% 1/16W
R716 1-216-821-11 METAL CHIP 1K 5% 1/16W
R717 1-216-821-11 METAL CHIP 1K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-809-11 METAL CHIP 100 5% 1/16W
R720 1-216-809-11 METAL CHIP 100 5% 1/16W
R721 1-216-821-11 METAL CHIP 1K 5% 1/16W
R722 1-216-809-11 METAL CHIP 100 5% 1/16W
R723 1-216-809-11 METAL CHIP 100 5% 1/16W
R724 1-216-841-11 METAL CHIP 47K 5% 1/16W
R725 1-216-819-11 METAL CHIP 680 5% 1/16W
R726 1-216-819-11 METAL CHIP 680 5% 1/16W
R727 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R728 1-216-833-11 METAL CHIP 10K 5% 1/16W
R729 1-216-813-11 METAL CHIP 220 5% 1/16W
R730 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R741 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R743 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R744 1-216-845-11 METAL CHIP 100K 5% 1/16W
< SWITCH >
S701 1-762-812-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-795-173-21 VIBRATOR, CERAMIC (33.86MHz)
*************************************************************
* 1-679-966-11 CONTROL (1) BOARD (FORMER)
******************
< CONNECTOR >
CNP401 1-770-516-31 CONNECTOR, FFC 8P
< JUMPER RESISTOR >
JC401 1-216-864-11 METAL CHIP 0 5% 1/16W
JC402 1-216-864-11 METAL CHIP 0 5% 1/16W
< CABLE HOLDER >
* KH402 1-565-386-11 HOLDER, CABLE 5P
* KH403 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R401 1-216-819-11 METAL CHIP 680 5% 1/16W
R402 1-216-815-11 METAL CHIP 330 5% 1/16W
R403 1-216-817-11 METAL CHIP 470 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R406 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R407 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R408 1-216-835-11 METAL CHIP 15K 5% 1/16W
R413 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R417 1-216-819-11 METAL CHIP 680 5% 1/16W
R418 1-216-815-11 METAL CHIP 330 5% 1/16W
R419 1-216-817-11 METAL CHIP 470 5% 1/16W
R420 1-216-821-11 METAL CHIP 1K 5% 1/16W
R421 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R422 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R423 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R424 1-216-835-11 METAL CHIP 15K 5% 1/16W
R425 1-216-819-11 METAL CHIP 680 5% 1/16W
R426 1-216-815-11 METAL CHIP 330 5% 1/16W
R427 1-216-817-11 METAL CHIP 470 5% 1/16W
R428 1-216-821-11 METAL CHIP 1K 5% 1/16W
R429 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R430 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R431 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R432 1-216-835-11 METAL CHIP 15K 5% 1/16W
R440 1-216-815-11 METAL CHIP 330 5% 1/16W
R441 1-216-815-11 METAL CHIP 330 5% 1/16W
CONTROL (1)CD
