Sony CFD-S36 - Electrical Parts List; Battery Terminal and Connector Parts; Capacitors, Coils, and Filters

41
CFD-S36
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BATTERY TERMINAL (1)
* 1-679-964-11 BATTERY TERMINAL (1) BOARD
**************************
3-028-154-01 TERMINAL (–), BATTERY
*************************************************************
* 1-679-965-11 BATTERY TERMINAL (2) BOARD
**************************
3-028-154-01 TERMINAL (–), BATTERY
< CONNECTOR >
* CNP904 1-580-163-11 PIN, CONNECTOR (PC BOARD) 2P
*************************************************************
* A-3347-089-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-104-664-11 ELECT 47uF 20% 10V
C703 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C704 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C705 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C706 1-126-960-11 ELECT 1uF 20% 50V
C707 1-115-156-11 CERAMIC CHIP 1uF 10V
C708 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C709 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C711 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C712 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C713 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C716 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C717 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C720 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C721 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C722 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C723 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C724 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C725 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C726 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C727 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C728 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C729 1-125-837-00 CERAMIC CHIP 1uF 10% 6.3V
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C731 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C732 1-104-665-11 ELECT 100uF 20% 10V
C733 1-104-665-11 ELECT 100uF 20% 10V
C734 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C735 1-126-916-11 ELECT 1000uF 20% 6.3V
C736 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C739 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C740 1-126-935-11 ELECT 470uF 20% 10V
C741 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C742 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C743 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C744 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C745 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C746 1-104-665-11 ELECT 100uF 20% 10V
C747 1-104-665-11 ELECT 100uF 20% 10V
C750 1-104-665-11 ELECT 100uF 20% 10V
C751 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CNP701 1-779-466-11 CONNECTOR, FFC (LIF(NON-ZIF)) 16P
* CNP702 1-784-736-11 CONNECTOR, FFC 14P
< FERRITE BEAD >
FB701 1-469-701-21 INDUCTOR, FERRITE BEAD
< IC >
IC701 8-759-830-25 IC LC78645E
IC702 8-759-591-62 IC BA6998FP
< JUMPER RESISTOR >
JC701 1-216-864-11 SHORT 0
JC702 1-216-864-11 SHORT 0
JC703 1-216-864-11 SHORT 0
JC704 1-216-813-11 METAL CHIP 220 5% 1/16W
< COIL >
L706 1-414-445-11 FERRITE, EMI (SMD)
< TRANSISTOR >
Q701 8-729-054-57 TRANSISTOR KTN2907AS-RTK
< RESISTOR >
R701 1-216-841-11 METAL CHIP 47K 5% 1/16W
R702 1-216-835-11 METAL CHIP 15K 5% 1/16W
R703 1-216-835-11 METAL CHIP 15K 5% 1/16W
R704 1-216-835-11 METAL CHIP 15K 5% 1/16W
CD
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
BATTERY TERMINAL (2)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
• Abbreviation
CND : Canadian model E4 : AC 110-120V/220-240V area in E model
MX : Mexican model E92 : AC 120V area in E model
SP : Singapore model AR : Argentina model
