43
CFD-S36
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-679-967-11 CONTROL (2) BOARD
******************
< CONNECTOR >
* CNP404 1-815-553-11 PIN, CONNECTOR (PC BOARD) 5P
< IC >
IC401 8-749-018-72 IC SPS-442-E
< RESISTOR >
R409 1-216-819-11 METAL CHIP 680 5% 1/16W
R410 1-216-815-11 METAL CHIP 330 5% 1/16W
R411 1-216-817-11 METAL CHIP 470 5% 1/16W
R412 1-216-821-11 METAL CHIP 1K 5% 1/16W
R437 1-216-849-11 METAL CHIP 220K 5% 1/16W
R438 1-216-845-11 METAL CHIP 100K 5% 1/16W
R439 1-216-815-11 METAL CHIP 330 5% 1/16W
< SWITCH >
S407 1-786-050-21 SWITCH, KEYBOARD (CD)
S408 1-786-050-21 SWITCH, KEYBOARD (TAPE)
S409 1-786-050-21 SWITCH, KEYBOARD
(RADIO BAND•AUTO PRESET)
*************************************************************
* 1-679-968-11 CONTROL (3) BOARD
******************
< DIODE >
D451 8-719-059-97 LED L-34HD (OPR/BATT)
< CABLE HOLDER >
* KH405 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R414 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R415 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R416 1-216-835-11 METAL CHIP 15K 5% 1/16W
R434 1-216-817-11 METAL CHIP 470 5% 1/16W
R435 1-216-813-11 METAL CHIP 220 5% 1/16W
R436 1-216-811-11 METAL CHIP 150 5% 1/16W
< SWITCH >
S411 1-786-050-21 SWITCH, KEYBOARD (DISPLAY ENT•MEMORY)
S412 1-786-050-21 SWITCH, KEYBOARD (MODE)
*************************************************************
* A-3062-383-A MAIN BOARD, COMPLETE (SP)
* A-3062-384-A MAIN BOARD, COMPLETE (AR)
* A-3062-385-A MAIN BOARD, COMPLETE (E4)
* A-3347-211-A MAIN BOARD, COMPLETE (CND,E92,MX)
*********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C1 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C4 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C8 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C10 1-115-871-11 ELECT 1uF 20% 50V
C11 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C12 1-126-794-11 ELECT 4.7uF 20% 50V
C14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(E4,SP,AR)
C14 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(CND,E92,MX)
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(E4,SP,AR)
C15 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(CND,E92,MX)
C16 1-115-871-11 ELECT 1uF 20% 50V
C17 1-115-871-11 ELECT 1uF 20% 50V
C18 1-126-176-11 ELECT 220uF 20% 10V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-115-871-11 ELECT 1uF 20% 50V
C22 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C23 1-115-871-11 ELECT 1uF 20% 50V
C24 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C26 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C27 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C29 1-126-382-11 ELECT 100uF 20% 10V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C31 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C37 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C39 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C41 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C42 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C43 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C47 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C49 1-161-051-00 CERAMIC 0.01uF 10% 50V
C51 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C52 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C53 1-136-169-00 FILM 0.22uF 5% 50V
C54 1-126-176-11 ELECT 220uF 20% 10V
C55 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
CONTROL (2) CONTROL (3)
MAIN
