Sony CFD-S36 - ICs, Transistors, Diodes, and Resistors

45
CFD-S36
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< TRIMMER >
CT1 1-141-603-21 CAP, ADJ 20PF
CT3 1-141-601-21 CAP, ADJ 10PF
< DIODE >
D1 8-719-078-48 DIODE KV1471ETR1-3
D2 8-719-078-48 DIODE KV1471ETR1-3
D3 8-719-050-69 DIODE KV1520N
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D323 8-719-988-61 DIODE 1SS355TE-17
D324 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-083-39 DIODE KDZ5.1V-RTK
D802 8-719-082-07 DIODE KDS121-RTK
D803 8-719-082-07 DIODE KDS121-RTK
D804 8-719-082-07 DIODE KDS121-RTK
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-083-93 DIODE KDS120-RTK
D951 8-719-988-61 DIODE 1SS355TE-17
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-084-00 DIODE KDZ7.5V-RTK
D957 8-719-082-09 DIODE KDZ3.9V-RTK
< IC >
IC1 8-759-662-67 IC TA2149N
IC2 8-759-483-40 IC LC72137M-TLM
IC302 8-759-539-45 IC M62429P
IC304 8-759-426-51 IC BA5417
IC801 8-759-658-46 IC S-81233SGY-Z
IC802 8-759-712-09 IC uPD789477-907
IC803 8-759-487-03 IC BR24C01AF-WE2
IC804 8-759-645-87 IC PST9128-T
< JACK >
J321 1-815-325-11 JACK (i)
< JUMPER RESISTOR >
JC1 1-216-864-11 SHORT 0
JC2 1-216-864-11 SHORT 0
JC3 1-216-864-11 SHORT 0
JC4 1-216-864-11 SHORT 0
JC5 1-216-864-11 SHORT 0
JC6 1-216-864-11 SHORT 0
JC11 1-216-864-11 SHORT 0
JC12 1-216-864-11 SHORT 0
JC23 1-216-864-11 SHORT 0
JC24 1-216-864-11 SHORT 0
JC302 1-216-864-11 SHORT 0
JC303 1-216-864-11 SHORT 0
JC304 1-216-864-11 SHORT 0
JC305 1-216-864-11 SHORT 0
JC306 1-216-864-11 SHORT 0
JC307 1-216-864-11 SHORT 0
JC308 1-216-864-11 SHORT 0
< CABLE HOLDER >
* KH321 1-565-385-11 HOLDER, CABLE 4P
* KH803 1-573-287-11 HOLDER, CABLE 2P
< COIL >
L1 1-409-775-21 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
L3 1-424-708-11 ANTENNA, FERRITE-ROD (AM)
L4 1-411-234-21 COIL, AM OSC
L21 1-410-509-11 INDUCTOR 10uH
L801 1-414-137-31 INDUCTOR 0.22uH (E4,SP,AR)
L801 1-469-540-61 INDUCTOR 0.22uH (CND,E92,MX)
L802 1-410-521-11 INDUCTOR 100uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-804-243-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q122 8-729-054-58 TRANSISTOR KTC4075-RTK
Q124 8-729-054-24 TRANSISTOR KRC410-RTK
Q125 8-729-054-58 TRANSISTOR KTC4075-RTK
Q222 8-729-054-58 TRANSISTOR KTC4075-RTK
Q224 8-729-054-24 TRANSISTOR KRC410-RTK
Q225 8-729-054-58 TRANSISTOR KTC4075-RTK
Q301 8-729-054-58 TRANSISTOR KTC4075-RTK
Q801 8-729-054-21 TRANSISTOR KRC407-RTK
Q804 8-729-054-07 TRANSISTOR KRA307-RTK
Q806 8-729-054-07 TRANSISTOR KRA307-RTK
Q807 8-729-212-02 TRANSISTOR 2SC2120-Y
Q808 8-729-054-21 TRANSISTOR KRC407-RTK
Q812 8-729-054-14 TRANSISTOR KRA314-RTK
Q813 8-729-054-21 TRANSISTOR KRC407-RTK
Q814 8-729-054-21 TRANSISTOR KRC407-RTK
Q817 8-729-055-41 TRANSISTOR KTB1241Y-AT
Q818 8-729-054-21 TRANSISTOR KRC407-RTK
Q819 8-729-054-18 TRANSISTOR KRC404-RTK
Q820 8-729-054-23 TRANSISTOR KRC409-RTK
Q951 8-729-054-15 TRANSISTOR KRC401-RTK
Q952 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q953 8-729-054-15 TRANSISTOR KRC401-RTK
Q955 8-729-021-82 TRANSISTOR 2SD2396K
Q957 8-729-212-02 TRANSISTOR 2SC2120-Y
< RESISTOR >
R1 1-216-815-11 METAL CHIP 330 5% 1/16W
R2 1-216-817-11 METAL CHIP 470 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-833-11 METAL CHIP 10K 5% 1/16W
R10 1-216-805-11 METAL CHIP 47 5% 1/16W
