CFD-S36
Ref. No. Part No. Description Remark
< CONNECTOR >
CNP301 1-568-830-11 CONNECTOR, FFC 11P
< IC >
IC301 8-759-264-71 IC TA2068N
< JUMPER RESISTOR >
JC301 1-216-864-11 SHORT 0
JC302 1-216-864-11 SHORT 0
JC303 1-216-864-11 SHORT 0
JC304 1-216-864-11 SHORT 0
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-807-11 METAL CHIP 68 5% 1/16W
R103 1-216-843-11 METAL CHIP 68K 5% 1/16W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R105 1-216-835-11 METAL CHIP 15K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R110 1-216-809-11 METAL CHIP 100 5% 1/16W
R111 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R201 1-216-835-11 METAL CHIP 15K 5% 1/16W
R202 1-216-807-11 METAL CHIP 68 5% 1/16W
R203 1-216-843-11 METAL CHIP 68K 5% 1/16W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R205 1-216-835-11 METAL CHIP 15K 5% 1/16W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R210 1-216-025-11 RES-CHIP 100 5% 1/10W
R211 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R301 1-216-857-11 METAL CHIP 1M 5% 1/16W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R304 1-216-821-11 METAL CHIP 1K 5% 1/16W
R305 1-216-811-11 METAL CHIP 150 5% 1/16W
R306 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R307 1-216-799-11 METAL CHIP 15 5% 1/16W
R308 1-216-837-11 METAL CHIP 22K 5% 1/16W
R309 1-216-805-11 METAL CHIP 47 5% 1/16W
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
PRE
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
* 1-682-250-14 VOLTAGE SELECT BOARD (E4)
*********************
< SWITCH >
0 S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR) (E4)
*************************************************************
MISCELLANEOUS
***************
* 11 1-757-559-11 CABLE, FLAT 8P
* 102 1-757-560-11 CABLE, FLAT 11P
117 1-452-899-11 MAGNET
124 1-792-684-11 WIRE (FLAT TYPE) (16 CORE)
* 125 1-757-561-11 CABLE, FLAT 14P
0 251 8-848-483-05 PICK-UP, OPTICAL KSS-213C/Q-RP
255 X-2646-381-1 CHASSIS ASSY (MB), MOTOR (SPINDLE)
(including M701)
ANT1 1-501-883-21 ANTENNA, TELESCOPIC (E4,SP,AR)
ANT1 1-754-179-11 ANTENNA, TELESCOPIC (3 STEP) (CND,E92,MX)
0 F902 1-532-388-51 FUSE, TIME-LAG (T2AL/250V) (E4)
0 F902 1-533-469-11 FUSE, TIME-LAG (T2.5AL/250V) (SP,AR)
0 F902 1-533-470-11 FUSE, GLASS TUBE (DIA.5) (3.15A/250V) (CND)
HE301 1-543-876-11 HEAD (ERASE)
HRP301 1-500-668-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
M702 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
M801 A-3320-446-A MOTOR ASSY (CAPSTAN/REEL)
S801 1-692-960-11 SWITCH, PUSH (1 KEY) (Z PUSH OPEN/CLOSE)
S802 1-762-679-11 SWITCH, LEAF (TAPE PLAY)
SP301 1-529-723-21 SPEAKER (10cm) (L-CH)
SP302 1-529-723-21 SPEAKER (10cm) (R-CH)
0 T901 1-435-917-11 TRANSFORMER, POWER (E92,MX)
0 T901 1-435-918-11 TRANSFORMER, POWER (SP,AR)
0 T901 1-435-919-11 TRANSFORMER, POWER (E4)
0 T901 1-437-351-11 TRANSFORMER, POWER (CND)
*************************************************************
Ref. No. Part No. Description Remark
VOLTAGE SELECT
