Sony CFD-V3 Service Manual

6
CFD-V3/V7/V7L
3-3. CABINET (UPPER)
8
9
6
Screw +BVTP 3 × 10
5 Screw +BVTP 3 × 12
1 Screws
+BVTP 3
× 12
4 Screw
+BVTP 3
× 12
Remove the handle in
the direction of the arrow.
2 Open the Holder assy, cassette by
pressing STOP/EJECT button.
3 Open the Lid (CD)
Cabinet (rear)
Cabinet (upper)
STOP/EJECT
button
7 CNP902
(POWER board)
3-4. POWER BOARD, INLET BOARD, BATT (R) BOARD, BATT (L) BOARD
2 Screws
+BVTP 3 × 10
1 Screws
+BVTP 3 × 10
INLET board
POWER board
Cabinet (rear)
BATT (R) board
CNP907
BATT (L) board
5 Screws
+WH 3
× 8
6 CNP90
8
4 CNP907
3
8
7
