– 5 –
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. CABINET (FRONT) SUB ASSY
3-2. CONTROL BOARD, CONNECTOR BOARD
z
The equipment can be removed using the following procedure.
Cabinet (front) sub ASSY
Control board, Connecter board
Cabinet (rear) Cabinet (upper)
Set
Volume board, LCD board, Main board
REC switch board, Mechanism deck, Optical pick-up section, CD motor board
Belt, M601 (capstan/reel motor)
Power board, Secondary board, Half battery board, battery board
Cabinet (front) sub assy
cabinet (rear)
Lid, battery case
3
Screws
+BVTP 3
×
12
6
Open the Lid (CD)
2
Screws
+BVTP 3
×
10
4
Screw
+BVTP 3
×
10
7
Screw
+BVTP 3
×
12
9
5
1
8
Knob (Vol )
Cabinet (Front) sub assy
CONTROL board
1
Screws
+BVTP 2.6
×
8
2
Connector board
To Next Page
