– 6 –
3-3. CABINET (REAR)
7
8
5
Screws +BVTP 3 × 10
5 Screw +BVTP 3 × 12
1 Screws
+BVTP 3
× 12
4 Screw
+BVTP 3
× 12
Remove the Handle in
the direction of the arrow.
2 Open the Holder assy, cassette by
pressing STOP/EJECT button.
3 Open the Lid (CD)
Cabinet (rear)
Cabinet (Upper
)
STOP/EJECT
button
6 CNP902
(POWER board)
3-4. POWER BOARD, SECONDARY BOARD, HALF BATTERY BOARD, BATTERY BOARD
2 Screws
+BVTP 3
× 10
1 Screws
+BVTP 3
× 10
POWER board
Secondary board
Cabinet (rear)
Battery board
HALF Battery board
5 Screws
+WH 3
× 8
6 CNP90
8
4 CNP907
3
8
7
