12 Speaker
13 Strap hole
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet
before using the touchscreen. Otherwise, the touchscreen might not function properly.
To remove the back cover
• Insert a fingernail into the gap (as shown in the illustration) and lift up the cover.
To insert the SIM card
• Remove the battery cover and the battery, then insert the SIM card into its slot
with the gold-colored contacts facing down.
To insert a memory card
1 Remove the back cover and the battery.
2 Insert the memory card into the memory card slot, with the gold-colored
contacts facing down.
7
