Sony DCR-PC103E - Battery Holder

2-6
DCR-PC103E/PC104E/PC105/PC105E
2-7. BATTERY HOLDER
4 Screw
6 Battery bracket
5 Radiation sheet (R)
7 Flip over the BJ-004 board.
8 Battery holder
Radiation sheet (R)
Battery bracket
1 Two screws
(M1.7
× 2.5),
lock ace, p2
2 Four screws (M1.7 × 4),
lock ace, p2
3 Screw
(M1.7
× 2.5),
lock ace, p2
Caution
