4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
no mark : side A
* mark : side B
VF-156
* C5301 D-3
* C5302 C-3
* C5401 B-6
* C5501 D-3
* C5502 D-3
* C5503 D-3
* C5504 C-3
* C5505 D-3
* C5506 D-3
* C5510 C-3
* C5511 C-3
* C5512 D-3
* C5513 D-3
* C5514 D-3
* C5515 C-3
* C5516 C-4
* C5517 D-4
* C5518 D-3
* C5519 C-4
* C5520 D-4
* C5521 C-4
* C5522 D-4
* C5523 D-4
* C5524 C-3
* C5525 C-4
* C5527 D-4
* C5528 D-4
* C5529 C-4
* C5529 D-4
* C5530 C-4
* C5531 D-4
* C5533 D-4
* C5534 D-4
* C5535 D-3
* C5536 D-3
* C5537 D-3
* C5538 D-3
C5539 D-4
C5601 B-2
C5602 A-2
C5604 B-2
CN5301 D-5
* CN5302 D-3
* CN5303 C-3
CN5405 A-5
CN5602 B-1
* D5301 D-3
* D5302 D-3
* D5407 B-5
* D5408 B-5
D5601 B-1
D5602 B-1
* FB530 D-3
* FB5301 D-3
* FB5303 D-3
FB5405 B-6
FB5406 B-6
* FB5408 B-5
* FB5409 B-5
FB5410 B-6
FB5411 B-6
FB5412 B-6
FB5413 B-6
FB5414 B-6
* IC5501 D-4
IC5601 B-2
J5402 A-5
J5403 A-6
L5501 D-4
Q5601 B-2
Q5602 A-2
Q5603 B-2
* R5411 B-6
* R5501 D-3
* R5502 D-3
* R5503 D-3
VF-156 BOARD
* R5504 D-3
* R5505 D-3
* R5506 D-3
* R5507 D-3
* R5508 D-4
* R5509 C-4
* R5510 C-4
* R5511 D-4
* R5512 D-4
* R5513 C-4
* R5514 D-4
* R5515 D-4
* R5516 C-4
* R5517 C-4
* R5518 D-4
* R5519 C-4
* R5520 D-4
* R5521 C-4
* R5522 D-4
* R5523 D-4
* R5524 D-4
* R5525 D-4
* R5526 D-3
* R5527 D-3
* R5528 D-3
* R5529 D-3
* R5530 D-4
* R5531 D-4
* R5532 C-4
R5603 B-2
R5604 B-2
R5605 A-2
R5607 B-2
R5608 B-2
R5609 B-2
R5610 B-2
R5611 B-2
R5612 B-2
TH5601 A-2
VD5401 B-6
VD5402 B-6
VD5403 B-6
VD5404 B-6
VD5405 B-6
VD5406 B-6
VD5407 B-6
VD5408 B-6
Mounted parts location of the VC-319
board is not shown.
Pages from 4-89 to 4-90 is not shown.
