Sony DCR-PC103E - Hp Retainer Assembly, Memory Stick; Connector (Pc105;Pc105 E)

2-20
DCR-PC103E/PC104E/PC105/PC105E
2-25. HP RETAINER ASSEMBLY, MEMORY STICK CONNECTOR (PC105/PC105E)
Memory stick connector
Control switch block
(FK4400)
5 Three screws
(M1.7
× 2.5),
lock ace, p2
8 Memory stick
connector
4 Control switch block
(FK4400) (6P)
6 Control switch
block (FK4400)
(10P)
7 Two claws
Caution
3 HP retainer
assembly
2 Claw
1 Screw
(M1.7 × 2.5),
lock ace, p2
(PC105/PC105E)
