5-18
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-TRV255E/TRV260/TRV265/TRV265E
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
VC-344
C4512 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4514 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4515 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4516 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4517 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4518 1-218-977-11 RES-CHIP 100K 5% 1/16W
(Note)
C4519 1-218-977-11 RES-CHIP 100K 5% 1/16W
(Note)
C4520 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5002 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5003 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C5004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5005 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C5006 1-100-249-11 CERAMIC CHIP 0.01uF 10% 16V
C5008 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C5009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5010 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C5401 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5404 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5405 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5408 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5409 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5410 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5411 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5413 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5414 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5416 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5418 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5419 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5420 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5421 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5422 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5423 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5424 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C5427 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5430 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5431 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5433 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5435 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5436 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5437 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5438 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C5439 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5440 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5441 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C5442 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5443 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C5445 1-135-158-21 TANTAL. CHIP 15uF 20% 4V
C5446 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6501 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6502 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6503 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6504 1-124-779-00 ELECT CHIP 10uF 20% 16V
C6506 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6507 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6509 1-126-209-11 ELECT CHIP 100uF 20% 4V
C6510 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C6511 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C6512 1-126-209-11 ELECT CHIP 100uF 20% 4V
< CONNECTOR >
CN1001 1-818-076-11 CONNECTOR, FFC/FPC (ZIF) 36P
CN1003 1-794-998-31 PIN, CONNECTOR 20P
CN1007 1-779-335-21 CONNECTOR, FFC/FPC 22P
CN1008 1-794-057-21 PIN, CONNECTOR (PC BOARD) 2P
CN1009 1-766-677-21 CONNECTOR, FFC/FPC 16P
CN1011 1-766-677-21 CONNECTOR, FFC/FPC 16P
CN1013 1-779-328-21 CONNECTOR, FFC/FPC 8P
CN1501 1-779-331-11 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 14P
CN1551 1-750-360-21 FFC/CONNECTOR, FPC (ZIF) 24P
* CN2401 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN2402 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN2403 1-816-179-11 CONNECTOR, FFC/FPC (ZIF) 22P
CN2404 1-766-345-21 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 15P
CN3201 1-766-341-21 CONNECTOR, FFC/FPC 11P
CN4001 1-573-806-21 PIN, CONNECTOR (1.5MM)(SMD) 6P
< DIODE >
D1006 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D1007 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D1009 6-500-314-01 DIODE DAN222MT2L
D1010 8-719-069-57 DIODE UDZSTE-176.8B
D1011 6-500-776-01 DIODE MAZW068H0LS0
D1012 6-500-776-01 DIODE MAZW068H0LS0
D1301 8-719-027-76 DIODE 1SS357-TPH3
D1302 6-500-314-01 DIODE DAN222MT2L
D1303 8-719-074-08 DIODE MA4ZD03001S0
D1305 8-719-074-08 DIODE MA4ZD03001S0
D1306 8-719-074-08 DIODE MA4ZD03001S0
D1501 8-719-082-63 DIODE 1SV329 (TPL3)
D1551 8-719-073-01 DIODE MA111-(K8).S0
D4001 8-719-074-08 DIODE MA4ZD03001S0
D4002 6-500-776-01 DIODE MAZW068H0LS0
D5001 8-719-073-01 DIODE MA111-(K8).S0
< FUSE >
0 F001 1-576-406-21 FUSE (1.4A/32V)
0 F002 1-576-406-21 FUSE (1.4A/32V)
0 F003 1-576-406-21 FUSE (1.4A/32V)
0 F004 1-576-406-21 FUSE (1.4A/32V)
< FERRITE BEAD >
FB1501 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB1504 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB1601 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB2401 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB2402 1-500-283-11 INDUCTOR, FERRITE BEAD
FB2403 1-500-283-11 INDUCTOR, FERRITE BEAD
FB3301 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3302 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3303 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB4501 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC1001 6-702-302-01 IC TK11133CSCL-G
Note: Resistors are mounted to the location
where C4518, C4519 are printed.
To Next Page
