5-19
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-TRV255E/TRV260/TRV265/TRV265E
VC-344
IC1301 6-705-264-01 IC MB44A120BPFV-G-BND-ERE1
IC1302 6-703-228-01 IC TK11160CSCL-G
IC1501 8-752-417-70 IC CXD2444AR-T4
IC1502 6-703-146-01 IC HD49337AFEB
IC1552 8-759-681-42 IC NJM12902V (TE2)
IC1553 8-759-637-96 IC uPD16877MA-6A5-E2
IC1554 8-759-693-13 IC NJM12904V (TE2)
IC1601 6-701-985-01 IC BH2220FVM-TR
IC2401 6-705-676-01 IC TB6550FG (O, EB)
IC3201 8-752-106-95 IC CXA3619R-T4
IC3301 8-752-418-16 IC CXD3164R
IC3302 8-759-566-52 IC SN104266PN-TEB
IC4501 6-803-882-01 IC MB91194APFF-G-155-BNDE1 (Note)
IC4502 6-705-122-01 IC BR25C320FV-WE2
IC5001 6-803-798-01 IC MB89097PFV-G-170-BND-ERE1
IC5401 6-701-074-01 IC LA74207W-TBM-E
IC5402 8-759-647-71 IC AK4550VT-E2
IC6501 6-705-159-01 IC NJM2570AV (TE2)
< COIL >
L1301 1-416-670-11 INDUCTOR 33uH
L1302 1-419-354-21 INDUCTOR 22uH
L1303 1-419-354-21 INDUCTOR 22uH
L1304 1-416-670-11 INDUCTOR 33uH
L1305 1-419-354-21 INDUCTOR 22uH
L1306 1-419-354-21 INDUCTOR 22uH
L1307 1-419-354-21 INDUCTOR 22uH
L1308 1-469-523-91 INDUCTOR 2.2uH
L1309 1-469-524-91 INDUCTOR 4.7uH
L1310 1-412-056-11 INDUCTOR 4.7uH
L1311 1-469-525-91 INDUCTOR 10uH
L1312 1-469-524-91 INDUCTOR 4.7uH
L1313 1-469-524-91 INDUCTOR 4.7uH
L1314 1-469-524-91 INDUCTOR 4.7uH
L1315 1-469-526-91 INDUCTOR 22uH
L1316 1-469-527-91 INDUCTOR 47uH
L1317 1-469-524-91 INDUCTOR 4.7uH
L1318 1-469-524-91 INDUCTOR 4.7uH
L1319 1-469-524-91 INDUCTOR 4.7uH
L1320 1-469-524-91 INDUCTOR 4.7uH
L1501 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L1551 1-414-398-11 INDUCTOR 10uH
L1553 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3201 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3202 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3203 1-414-406-41 INDUCTOR 220uH
L3204 1-400-197-11 INDUCTOR 12uH
L3305 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3307 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3310 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3313 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3320 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L3321 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L6501 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
< TRANSISTOR >
Q1001 8-729-402-84 TRANSISTOR XN4601
Q1002 6-550-242-01 TRANSISTOR DTC114EMT2L
Q1301 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q1302 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q1303 8-729-054-50 TRANSISTOR UP04501008S0
Q1304 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q1305 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1306 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1307 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1308 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1309 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1310 6-550-405-01 TRANSISTOR CPH5815-TL-E
Q1311 6-550-560-01 TRANSISTOR CPH5819-TL-E
Q1312 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q1313 8-729-054-50 TRANSISTOR UP04501008S0
Q1314 8-729-054-49 TRANSISTOR UP04401008S0
Q1315 8-729-216-22 TRANSISTOR 2SA1162-G
Q1316 8-729-055-22 TRANSISTOR 2SA1734 (TE12L)
Q1317 8-729-054-50 TRANSISTOR UP04501008S0
Q1318 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q1320 8-729-054-50 TRANSISTOR UP04501008S0
Q1324 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q1325 8-729-054-49 TRANSISTOR UP04401008S0
Q1551 6-550-758-01 TRANSISTOR DTC113TMT2L
Q1554 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q1555 8-729-054-51 TRANSISTOR UP04116008S0
Q2401 6-550-283-01 TRANSISTOR UNR32A600LS0
Q3202 8-729-054-48 TRANSISTOR UP04601008S0
Q3203 6-550-234-01 TRANSISTOR UNR32A300LS0
Q3204 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q3205 8-729-047-19 TRANSISTOR 2SA1965-S-TL
Q3303 6-550-383-01 TRANSISTOR HN4A71FK (TE85R)
Q3307 6-550-239-01 TRANSISTOR DTA144EMT2L
Q3308 8-729-054-49 TRANSISTOR UP04401008S0
Q4001 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q4002 8-729-056-54 TRANSISTOR TPCS8302 (TE12L)
Q4003 8-729-055-22 TRANSISTOR 2SA1734 (TE12L)
Q4004 6-550-234-01 TRANSISTOR UNR32A300LS0
Q4501 6-550-234-01 TRANSISTOR UNR32A300LS0
Q4502 6-550-237-01 TRANSISTOR 2SC5658T2LQ/R
Q5001 8-729-041-43 TRANSISTOR HN1L02FU (TE85R)
Q5401 8-729-054-52 TRANSISTOR UP04216008S0
Q5403 6-550-240-01 TRANSISTOR DTA114TMT2L
Q5408 8-729-921-51 TRANSISTOR 2SD1834-T100
< RESISTOR >
R1001 1-218-949-11 RES-CHIP 470 5% 1/16W
R1003 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R1005 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R1006 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R1007 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R1008 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R1009 1-218-953-11 RES-CHIP 1K 5% 1/16W
R1014 1-218-940-11 RES-CHIP 82 5% 1/16W
R1025 1-218-990-11 SHORT CHIP 0
R1029 1-218-943-11 RES-CHIP 150 5% 1/16W
R1031 1-218-990-11 SHORT CHIP 0
R1032 1-218-943-11 RES-CHIP 150 5% 1/16W
R1034 1-218-953-11 RES-CHIP 1K 5% 1/16W
R1301 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
Note: Changing the data is needs when IC4501 is replaced.
Please refer to change of IC4501 in page 1-6.
