19
DP-RF6000
Pin No. Pin Name I/O Description
129 GPIO9 — Not used (Open)
130 GPIO13 — Not used (Open)
131 FSDATAN1 I Serial A/D data input from WM8738GED/R
132 VDD4 — Power supply (+2.5V)
133 VSS4 — Ground
134 FSCLKN1, STCCLK2 I Serial clock signal input from LC98052T-TLM-E
135 XSCS I DSP chip select signal input from MB90488BPFV-G-150E1
136 SCDIN I Serial data input from MB90488BPFV-G-150E1
137 VSS5 — Ground
138 VDD5 — Power supply (+2.5V)
139 GPIO12 — Not used (Open)
140 SCDOUT O Serial data output to MB90488BPFV-G-150E1
141 HINBSY O DSP HINBSY signal output to MB90488BPFV-G-150E1
142 SCCLK I Serial clock signal input from MB90488BPFV-G-150E1
143 UHS2 I Mode select signal (Pull up)
144 XRESET I DSP Reset signal input from MB90488BPFV-G-150E1
