Sony DSC-T77 - Page 50

5-7
Ref. No. Part No. Description Ref. No. Part No. Description
DSC-T77_L2
A-1557-173-A ST-199 FLEXIBLE BOARD, COMPLETE
******************************
< LITHIUM RECHARGEABLE BATTERY >
0BT001 1-756-813-11 LITHIUM RECHARGEABLE BATTERY
< CAPACITOR >
* C002 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C003 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C005 1-100-758-11 CERAMIC CHIP 0.047uF 10% 250V
C006 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
0*C901 1-114-874-11 ELECT 28uF 99% 315V
0*C902 1-114-873-11 ELECT 21.9uF 99% 315V
< DIODE >
0D003 6-501-096-01 DIODE CRF02 (TE85R)
* D004 6-501-861-01 DIODE CL-360S-TD4-X-TL
(AF ILLUMINATOR/SELF-TIMER)
< FLASH >
0FL001 1-480-964-11 FLASH UNIT (FL61210)
< IC >
0*IC001 6-712-975-01 IC BD4215NUV-E2
< COIL >
* L001 1-400-820-11 INDUCTOR 2.2uH
< TRANSISTOR >
0*Q001 6-551-922-01 TRANSISTOR RJP4002ASA-00-Q0
< RESISTOR >
R003 1-216-121-00 METAL CHIP 1M 5% 1/10W
R004 1-218-989-11 RES-CHIP 1M 5% 1/16W
R005 1-218-941-11 RES-CHIP 100 5% 1/16W
< TRANSFORMER >
0*T001 1-445-491-21 D.C.-D.C.CONVERTER TRANSFORMER
************************************************************
ST-199
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
• Refer to page 5-1 for mark 0.
Electrical parts list of the SY-207 board is
not shown.
Pages 5-8 to 5-11 are not shown.
