Sony DSC-T77 - Identifying Parts Overview; Disassembly Flow Overview

2-2
DSC-T77_L2
2-1. IDENTIFYING PARTS
SY-207
2-2-1. OVERALL SECTION
- Front Block
2-2-2. MAIN SECTION
- Lens Block
- SY-207 Board
- BT Lid Base
2-2-3. ST/REAR SECTION
- ST-199 Flexible Board
- LCD Block
- DISASSEMBLY FLOW -
SY-207 Board
ST-199 Flexible Board
Front Block
Frame Assy
Control Switch Block
(RL61210)
Loudspeaker
(1.0cm)
LCD Block
Lens Block
BT Lid Assy
Rear Cabinet Block
BT-044 Flexible Board
CD-743 Flexible Board
