BALANCE (balance)
Adjusts the sound balance: [RIGHT-15] – [CENTER] – [LEFT-15].
FADER (fader)
Adjusts the relative level: [FRONT-15] – [CENTER] – [REAR-15].
DSEE (digital sound enhancement engine)
Improves digitally compressed sound by restoring high frequencies lost in the compression process: [ON], [OFF].
This setting can be memorized for each source other than the radio.
AAV (advanced auto volume)
Adjusts the playback volume level of all playback sources to the optimum level: [ON], [OFF].
REARBASS ENH (rear bass enhancer)
Enhances the bass sound by applying a low pass filter setting to the rear speakers. This function allows the rear
speakers to work as a subwoofer if one is not connected.
(Available only when [SUBW DIRECT] is set to [OFF].)
SUBW DIRECT (subwoofer direct connection)
Adjusts the settings for the subwoofer connected to the rear speaker lead without a power amplifier.
(Available only when [RBE MODE] is set to [OFF].)
Be sure to connect a 2 Ω or 4 Ω to 8 Ω subwoofer to either of the rear speaker leads.
When using a 2 Ω subwoofer, set [SPEAKER LOAD] to [2 OHM]. Do not connect a speaker to the other rear speaker
lead.
Item Detail
RBE MODE (rear bass enhancer
mode)
Selects the rear bass enhancer mode: [1], [2], [3], [OFF].
LPF FREQ (low pass filter frequency)
Selects the subwoofer cut-off frequency: [50Hz], [60Hz], [80Hz], [100Hz],
[120Hz].
LPF SLOPE (low pass filter slope) Selects the LPF slope: [1], [2], [3].
Item Detail
SUBW MODE (subwoofer mode) Selects the subwoofer mode: [1], [2], [3], [OFF].
SUBW PHASE (subwoofer phase) Selects the subwoofer phase: [NORMAL], [REVERSE].
SUBW POS (subwoofer position)
Selects the subwoofer position: [NEAR], [NORMAL], [FAR].
(Available only when [F/R POSITION] is set to other than [OFF].)
LPF FREQ (low pass filter
frequency)
Selects the subwoofer cut-off frequency: [50Hz], [60Hz], [80Hz], [100Hz],
[120Hz].
LPF SLOPE (low pass filter slope) Selects the LPF slope: [1], [2], [3].
