8-5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS30/NS32/NS33/NS52P
R916 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R917 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R918 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R919 1-216-295-91 SHORT CHIP 0
R922 1-216-033-00 RES-CHIP 220 5% 1/10W
R924 1-216-041-00 RES-CHIP 470 5% 1/10W
R926 1-216-041-00 RES-CHIP 470 5% 1/10W
R927 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R928 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R929 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R939 1-216-017-91 RES-CHIP 47 5% 1/10W
R950 1-216-081-00 RES-CHIP 22K 5% 1/10W
R956 1-216-295-91 SHORT CHIP 0
R957 1-414-233-22 FERRITE 0UH
R958 1-414-233-22 FERRITE 0UH
R963 1-216-081-00 RES-CHIP 22K 5% 1/10W
IF-124 BOARD
************
<CAPACITOR>
C401 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C403 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C404 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C405 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C406 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C407 1-126-947-11 ELECT 47UF 20.00% 35V
C408 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C409 1-104-666-11 ELECT 220UF 20.00% 25V
C410 1-130-481-00 MYLAR 0.0068UF 5.00% 50V
C411 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C412 1-126-965-91 ELECT 22UF 20.00% 50V
C413 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C414 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C416 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C417 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
<DIODE>
D402 8-719-041-97 DIODE MA113-(TX)
D403 8-719-041-97 DIODE MA113-(TX)
D404 8-719-041-97 DIODE MA113-(TX)
D405 8-719-041-97 DIODE MA113-(TX)
D406 8-719-422-32 DIODE MA8047-M-TX
D407 6-501-147-01 DIODE LTL-1MHAE-112A (NS52P only)
<TERMINAL>
* ET401 1-537-738-21 TERMINAL, EARTH
* ET402 1-537-738-21 TERMINAL, EARTH
<IC>
IC404 6-805-304-01 IC 86CK74AFG-6A77(M
IC406 6-705-738-01 IC RPM7240-H13
IC407 6-702-302-01 IC TK11133CSCL-G
IC408 6-704-114-01 IC S-80828CNUA-B8NT2G
<CHIP CONDUCTOR>
JR401 1-216-295-91 SHORT CHIP 0
JR402 1-216-295-91 SHORT CHIP 0
JR403 1-216-295-91 SHORT CHIP 0
JR404 1-216-295-91 SHORT CHIP 0
JR405 1-216-295-91 SHORT CHIP 0
JR406 1-216-295-91 SHORT CHIP 0
JR407 1-216-295-91 SHORT CHIP 0
JR408 1-216-295-91 SHORT CHIP 0
JR409 1-216-295-91 SHORT CHIP 0
JR411 1-216-295-91 SHORT CHIP 0
JR412 1-216-295-91 SHORT CHIP 0
JR413 1-216-295-91 SHORT CHIP 0
JR414 1-216-295-91 SHORT CHIP 0
JR417 1-216-295-91 SHORT CHIP 0
JS401 1-216-295-91 SHORT CHIP 0 (NS30/NS32/NS33 )
JS402 1-216-295-91 SHORT CHIP 0 (NS52P only)
JS405 7-611-005-04 WIRE, TIN PLATING (NS52P only)
JS406 7-611-005-04 WIRE, TIN PLATING (NS52P only)
JS407 1-216-295-91 SHORT CHIP 0 (NS52P only)
<INDUCTOR>
L401 1-408-982-11 INDUCTOR 100UH
<FLUORESCENT>
ND401 1-519-795-11 VACUUM FLUORESCENT DISPLAY
<TRANSISTOR>
Q401 8-729-420-82 TRANSISTOR 2SD874A-R-TX
Q402 8-729-420-82 TRANSISTOR 2SD874A-R-TX
<RESISTOR>
R401 1-216-073-91 RES-CHIP 10K 5% 1/10W
R402 1-216-073-91 RES-CHIP 10K 5% 1/10W
R403 1-216-025-11 RES-CHIP 100 5% 1/10W
R404 1-216-025-11 RES-CHIP 100 5% 1/10W
R405 1-216-073-91 RES-CHIP 10K 5% 1/10W
R406 1-216-025-11 RES-CHIP 100 5% 1/10W
R407 1-216-025-11 RES-CHIP 100 5% 1/10W
R408 1-216-025-11 RES-CHIP 100 5% 1/10W
R409 1-216-025-11 RES-CHIP 100 5% 1/10W
R411 1-216-025-11 RES-CHIP 100 5% 1/10W
R413 1-216-073-91 RES-CHIP 10K 5% 1/10W
R414 1-216-073-91 RES-CHIP 10K 5% 1/10W
(NS52P only)
R415 1-216-073-91 RES-CHIP 10K 5% 1/10W
(NS30/NS32/NS33)
R416 1-216-073-91 RES-CHIP 10K 5% 1/10W
R417 1-216-073-91 RES-CHIP 10K 5% 1/10W
R418 1-216-073-91 RES-CHIP 10K 5% 1/10W
R419 1-216-073-91 RES-CHIP 10K 5% 1/10W
R420 1-216-027-00 RES-CHIP 120 5% 1/10W
R421 1-216-013-00 RES-CHIP 33 5% 1/10W
R422 1-216-097-11 RES-CHIP 100K 5% 1/10W
R423 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R424 1-216-017-91 RES-CHIP 47 5% 1/10W
IF-124ER-037
