8-6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS30/NS32/NS33/NS52P
R426 1-216-073-91 RES-CHIP 10K 5% 1/10W
R427 1-216-083-00 RES-CHIP 27K 5% 1/10W
R428 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R429 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R430 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R431 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R432 1-216-025-11 RES-CHIP 100 5% 1/10W
(NS52P only)
R433 1-216-073-91 RES-CHIP 10K 5% 1/10W
R434 1-216-073-91 RES-CHIP 10K 5% 1/10W
R435 1-216-073-91 RES-CHIP 10K 5% 1/10W
R436 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
(Except Russian model)
R436 1-216-081-00 RES-CHIP 22K 5% 1/10W
(Russian model only)
R437 1-216-081-00 RES-CHIP 22K 5% 1/10W
(Russian model only)
R440 1-216-295-91 SHORT CHIP 0
<SWITCH>
S401 1-771-410-21 SWITCH, TACT (NS30/NS32/NS33 )
S402 1-771-410-21 SWITCH, TACT
S403 1-771-410-21 SWITCH, TACT
S404 1-771-410-21 SWITCH, TACT
S405 1-771-410-21 SWITCH, TACT (NS30/NS32/NS33 )
S407 1-771-410-21 SWITCH, TACT
S408 1-771-410-21 SWITCH, TACT (NS52P only)
S409 1-771-410-21 SWITCH, TACT (NS52P only)
S410 1-771-410-21 SWITCH, TACT (NS52P only)
<TRANSFORMER>
T401 1-443-598-11 DC-DC CONVERTER TRANSFORMER
<VIBRATOR>
X401 1-781-472-21 VIBRATOR, CERAMIC
MS-203 BOARD
*************
<CONNECTOR>
CN001 1-815-412-11 CONNECTOR, FFC/FPC 5P
<SWITCH>
S001 1-786-693-11 SWITCH, DETECTION
S001 1-786-693-11 SWITCH, DETECTION
A-1102-280-A MV-045 COMPLETE (NS30:AEP,UK)
A-1102-282-A MV-045 COMPLETE (NS30:RUS)
A-1102-286-A MV-045 COMPLETE (NS32:RUS)
A-1102-288-A MV-045 COMPLETE (NS33)
A-1102-290-A MV-045 COMPLETE (NS52P:AEP,UK)
A-1115-358-A MV-045 COMPLETE (NS32:AEP)
A-1121-394-A MV-45 COMPLETE (NS52P:RUS)
*******************************
<CAPACITOR>
C101 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C102 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C105 1-126-786-11 ELECT 47UF 20.00% 16V
C106 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C112 1-126-786-11 ELECT 47UF 20.00% 16V
C113 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C115 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C116 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C117 1-126-964-11 ELECT 10UF 20.00% 50V
C118 1-126-964-11 ELECT 10UF 20.00% 50V
C119 1-126-964-11 ELECT 10UF 20.00% 50V
C120 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C121 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C122 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C123 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C124 1-165-908-11 CERAMIC CHIP 1UF 10% 10V
C125 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C127 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C128 1-162-965-11 CERAMIC CHIP 0.0015UF 10.00% 50V
C130 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C131 1-125-889-91 CERAMIC CHIP 2.2UF 10% 10V
C132 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C133 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C135 1-164-677-11 CERAMIC CHIP 0.033UF 10.00% 16V
C136 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C137 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C138 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C139 1-162-919-11 CERAMIC CHIP 22PF 5.00% 50V
C140 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C144 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C146 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C147 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C148 1-165-176-11 CERAMIC CHIP 0.047UF 10.00% 16V
C149 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C150 1-126-964-11 ELECT 10UF 20.00% 50V
C151 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C152 1-162-915-11 CERAMIC CHIP 10PF 0.50PF 50V
C153 1-162-917-11 CERAMIC CHIP 15PF 5.00% 50V
C154 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C155 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C156 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C158 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
C160 1-162-970-11 CERAMIC CHIP 0.01UF 10.00% 25V
MV-045IF-124
Notes:
MV-045 mounted PWB must be replaced
if IC103 (EEPROM IC) is damaged or not functioning.
The old MV-045 mounted PWB must be completely disposed.
