8-3
DVP-NS36/NS37/NS45P/NS55P/NS61P/NS63P
8-1-2. MECHANISM DECK ASSEMBLY
ns : not supplied
Ref. No. Part No. Description Remark
20 A-6071-669-C LOADING ASSY(M)
21 3-088-372-01 INSULATOR
22 3-087-599-01 INSULATOR SCREW
23 4-674-137-11 SCREW (PTP2X5)
24 3-088-371-01 BELT
25 4-974-725-11 SCREW (M1.7X2.5), P
26 8-820-321-05 DEVICE,OPTICAL KHM-313CAA/C2RP
21
21
20
22
22
22
21
22
21
23
24
26
25
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
To Next Page
