Sony FCB-EX1010 - Title Setting; Lens Control

48
Command List
Digital Zoom Combine mode
X12-NTSC/PAL
Digital Zoom Digital Zoom
Ratio Position Data
×1 4000
×2 6000
×3 6A80
×4 7000
×5 7300
×6 7540
×7 76C0
×8 7800
×9 78C0
×10 7980
×11 7A00
×12 7AC0
Digital Zoom Separate mode
X12-NTSC/PAL
Digital Zoom Digital Zoom
Ratio Position Data
×100
×280
×3AA
×4C0
×5CC
×6D5
×7DB
×8E0
×9E3
×10 E6
×11 E8
×12 EB
Lens control
Zoom Position
0000 to 4000 to 7AC0
Wide end Optical Digital
Tele end Tele end
Focus Position
1000 to C000
Far end Near end
1000: Over Inf
2000: 20 m
3000: 10 m
4000: 5 m As the distance on the left
Focus Near
5000: 3 m will differ due to temperature
Limit
6000: 2 m characteristics, etc., use as
7000: 1.5 m approximate values.
8000: 32 cm * The lower 1 byte is fixed at
9000: 9.5 cm 00.
A000: 4.5 cm
B000: 2 cm
C000: 1 cm
Register Setting
Line number 00 to 0A
H-position 00 to 17
Blink
00: Dose not blink
01: Blinks
00 White
01 Yellow
02 Violet
Color 03 Red
04 Cyan
05 Green
06 Blue
00 01 02 03 04 05 06 07
AB CDEF G H
08 09 0a 0b 0c 0d 0e 0f
IJKLMNOP
10 11 12 13 14 15 16 17
QR STUVWX
18 19 1a 1b 1c 1d 1e 1f
YZ & ? ! 1 2
20 21 22 23 24 25 26 27
34 5678 9 0
28 29 2a 2b 2c 2d 2e 2f
ÀÈ ÌÒÙÁ É Í
30 31 32 33 34 35 36 37
ÓÚ ÂÊÔÆŒÃ
38 39 3a 3b 3c 3d 3e 3f
ÕÑ Ç ßÄ Ï Ö Ü
40 41 42 43 44 45 46 47
Å$
F
¥DM£ ¿ ¡
48 49 4a 4b 4c 4d 4e 4f
ø“ : ‘ . , / -
Title setting
Register No. Value
VISCA 00 9600 bps
Baud Rate 00 01 19200 bps
02 38400 bps
OSD
60
00 English
Language 03 Chinese
