Locations of Controls
Locations of Controls
1 Lens
2 CN600 jack
3 CN601 jack
4 TELE button
5 WIDE button
6 CN702 jack (for key SW)
7 Tripod screw hole
When a tripod is used, please use
10 mm (
13
/32 in.) screw to attach it
to the camera. Also, please be
sure to attach the tripod securely.
Front
Back Bottom
Top
