PART No. DESCRIPTION MARK
51 4-547-397-02 BRACKET, WIFI BR6/AR4/ECU
51 4-564-318-01 BRACKET, WIFI UC2/LA1/LA8/
CR1/CO1
52 1-458-854-11 WLAN/BT MODULE (11N) Except BR6
52 1-458-854-21 WLAN/BT MODULE (11N) BRZ BR6
53 4-549-528-11 SHEET, THERMAL (SC)
54 4-547-395-01 COVER, TOP BR6/AR4/ECU
54 4-564-317-01 COVER, TOP UC2/LA1/LA8/
CR1/CO1
55 4-547-389-01 PANEL, ORNAMENT BR6/AR4/ECU
55 4-564-312-01 PANEL, ORNAMENT UC2/LA1/LA8/
CR1/CO1
56 4-547-390-01 LIGHT, GUIDE BR6/AR4/ECU
56 4-564-313-02 LIGHT, GUIDE UC2/LA1/LA8/
CR1/CO1
57 A-2066-088-A HSC3_S_M MOUNT UC2/LA1/LA8/
CR1/CO1/BR6
57 A-2074-616-A HSC3_S_M MOUNT KIT AR4/ECU
58 4-547-392-01 CASE, BOTTOM (M) BR6/AR4/ECU
58 4-564-315-01 CASE, BOTTOM (M) UC2/LA1/LA8/
CR1/CO1
71 4-559-310-01 STAND NECK ASSY (LAK) UC2/LA1/LA8/
CR1/CO1/ECU
71 A-2070-161-A STAND, NECK ASSY (LAK) SBR BR6
71 A-2076-425-A STAND, NECK ASSY (LAK) AR4
72 4-559-316-01 STAND, SHAFT (ML LAK) A UC2/LA1/LA8/
CR1/CO1/ECU
72 A-2070-160-A STAND, SHAFT (ML LAK) A SBR BR6
72 A-2076-424-A STAND, SHAFT (ML LAK) A AR AR4
17
1-1. KDL-50W800C/805C/807C/809C
1-1-1. Disassembly, Exploded View
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
