77
DIAGRAMS
4-3. CIRCUIT BOARDS LOCATION
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
<** SMART CORE BLOCK >
WLAN
MODULE
HSC3-S
MOUNT
SWITCH
UNIT
**SMART CORE
BMX BOARD
4-3-1. KDL-50W800C/805C/807C/809C
SWITCH
UNIT
**SMART CORE
BMX BOARD
4-3-2. KDL-55W800C/805C
