Sony GN1G - Smart Core Block; Stand Block

KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
20
STAND BLOCK
STAND, SHAFT
72
STAND NECK ASSY
71
SCREW, M4 LOCK
FOOT, REAR
FOOT, FRONT
STAND, SHAFT
SCREW, M4 LOCK
ARM L
ARM R
STAND, NECK
Stand exploded view are for reference purpose. (Child parts are
UNSTOCKED unless specified at 3-3-2: Screws & 3-3-4: Other
Parts )
56
BRACKET, WIFI
51
PANEL,
ORNAMENTAL
WLAN/BT
MODULE
COVER, TOP
LIGHT, GUIDE
SHEET,
THERMAL (SC)
HSC3_S MOUNT
CASE,
BOTTOM (M)
53
55
52
57
58
59
SMART CORE BLOCK
54
HEAT SINK(SC)
LABEL, UNDER
TERMINAL (TU)
10
BRACKET SIDE
BRACKET,
SC
17
6
7
UNDERCOVER
5
LABEL, SIDE
TERMINAL
LABEL, UNDER
TERMINAL
BMX BOARD
8
9
BRACKET UNDER
12
SWITCH
UNIT
4
BRACKET
UNDER, TU
18
POWER SUPPLY
CORD
2
This part is not stocked. The
purpose of indicated in this
illustrator is just for reference
only.
16
BRACKET,
SP
15
SPEAKER BOX
ASSY (R)
14
BT ANTENNA
11
SHEET, THERMAL
BRACKET, SP
14
13
SPEAKER BOX
ASSY (L)
19
LCD PANEL
1
AC ADAPTOR
3
LABEL, REAR
TERMINAL
1-2. KDL-55W800C/805C
1-2-1. Disassembly, Exploded View
