KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
23
REF. No. PART No. DESCRIPTION MARK
81 1-910-805-37 CONNECTOR ASSY 30P CN9000 (BMX) -CN4001 (LDB3B) (1)
82 1-910-805-36 HARNESS ASSY (BR6) CN1000 (BMX) -CN203 (SM) -CN101 (HSC3-S-M) - (WIFI/BT) / CN7751 (BMX) -SP (1)
82 1-910-805-48 HARNESS ASSY (Except BR6) CN1000 (BMX) -CN203 (SM) -CN101 (HSC3-S-M) - (WIFI/BT) / CN7751 (BMX) -SP (1)
83 1-848-833-11 FLEXIBLE FLAT CABLE 51P (BR) CN8400 (BMX) -T-CON (1)
83 1-848-834-11 FLEXIBLE FLAT CABLE 51P CN8400 (BMX) -T-CON (1)
(Except BR6)
1-2. KDL-55W800C/805C
1-2-3. Connectors
83
82
81
82
