APPENDIX-1

KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

1-1. Procedure To Disassemble Under Cover (Standing position)

94

Step 1: Ensure all screws is removed.

Step 2: Take out the UC

XMA 50””

X 16
